| Camera |
| Image sensor | Progressive scan RGB CMOS 1/4” |
| Lens | Fixed iris, Fixed focus
2.8 mm, F2.0
Horizontal angle of view: 81° Vertical angle of view: 44° |
| Light sensitivity | 1.0-10000 lux |
| Shutter time | 1/24500 s to 1/6 s
|
| Video |
| Video
compression | H.264 (MPEG-4 Part 10/AVC), Motion JPEG |
| Resolution | 1280x720 to 320x180
|
| Frame rate | Up to 25/30 fps (50/60 Hz) in all resolutions |
| Video streaming | Multiple, individually configurable streams in H.264 and Motion JPEG
Controllable frame rate and bandwidth, VBR/CBR H.264 |
| Image settings | Compression, Color, Brightness, Sharpness, Contrast, White balance, Exposure control, Exposure zones, Backlight compensation, Fine tuning of behavior at low light, Rotation, Text and image overlay, Mirroring of images, Privacy mask, Axis’ Corridor Format |
| Network |
| Security | Password protection, IP address filtering, HTTPSa encryption, IEEE 802.1Xa network access control, digest authentication, user access log, Centralized Certificate Management, brute force delay protection, signed firmware |
| Supported
protocols | IPv4/v6, HTTP, HTTPS, SSL/TLS, QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH |
| General
|
| Casing | Main unit: Polycarbonate casing
Sensor unit: IP66- and NEMA 4X-rated metal casing (aluminum) |
| Memory | 256 MB RAM, 128 MB Flash |
| Power | Power over Ethernet IEEE 802.3af/802.3at Type 1 Class 2 (max 6.49 W)
8-28 V DC max 4.7 W |
| Connectors | RJ45 for 10BASE-T/100BASE-TX PoE
RJ12 for the sensor unit
Terminal blocks for power, 1 alarm input and 1 output |
| Storage | Support for microSD/microSDHC/microSDXC card
Support for recording to dedicated network-attached storage (NAS)
For SD card and NAS recommendations see www.axis.com |
| Operating
conditions | -20 °C to 50 °C (-4 °F to 122 °F)
Main unit: Humidity 10-85% RH (non-condensing) Sensor unit: Humidity 10-100% RH (condensing)
|
| Storage conditions | -40°Cto65°C(-40°Fto149°F) |
| Approvals | EN 55022 Class B, EN 55024, EN 61000-3-2, EN 61000-3-3,
EN 61000-6-1, FCC Part 15 Subpart B Class B, ICES-003 Class B, VCCI Class B, C-tick AS/NZS CISPR 22 Class B,
KCC KN22 Class B, KN24, IEC/EN/UL 60950-1,
IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6 Class 4M4,
IEC 60068-2-27 Class 4M3, 60068-2-78 Class 3K3
Sensor unit: IEC/EN/UL 60950-22, IEC/EN 60529 IP66,
NEMA 250 Type 4X, IEC 60068-2-14, IEC 60068-2-30,
IEC 60068-2-78 Class 4K3
|
| Dimensions | ø 20 x 52 mm (13/16 x 2 1/16 in) |
| Weight | Main unit: 109 g (0.24 lb)
Sensor unit: 238 g (0.52 lb)
|
| Included
accessories | Mounting kit, Installation Guide, Windows decoder 1-user
license, AVHS Authentication key |
| Optional
accessories | Mounting brackets, AXIS T8120 Midspan 15 W 1-port, AXIS P7701 Video Decoder, AXIS P8221 Network I/O Audio Module |
| Video
management
software | AXIS Camera Companion, AXIS Camera Station, Video management software from Axis’ Application Development Partners available on www.axis.com/techsup/software |
| Languages | English, German, French, Spanish, Italian, Russian, Simplified
Chinese, Japanese, Korean, Portuguese, Traditional Chinese |
| Warranty | Axis 3-year warranty |
