| Camera |
| Image sensor | Progressive scan RGB CMOS 1/3" |
| Lens | Varifocal, IR corrected, CS-mount, DC-iris, 3–10.5 mm
Horizontal field of view: 91°–32°
Vertical field of view: 49°–18° |
| Day and night | Automatically removable IR cut filter |
| | Color: 0.25 lux F1.4
B/W: 0.05 lux F1.4
|
| Shutter time | 1/66500 to 1 s
|
| Pan/Tilt/Zoom D | Digital PTZ |
| Video |
| Video
compression | Automatically removable infrared-cut filter |
| Resolution | 1280x720 to 160x90
|
| Frame rate | Up to 25/30 fps (50/60 Hz) in all resolutions |
| Video streaming | Multiple, individually configurable streams in H.264 and Motion
JPEG
Axis Zipstream technology in H.264
Controllable frame rate and bandwidth, VBR/MBR H.264 |
| Image settings | WDR – forensic capture: up to 120 dB depending on scene,
manual shutter time, compression, color, brightness, sharpness,
contrast, white balance, exposure control (including automatic
gain control), exposure zones, fine tuning of behavior at low
light, rotation: 0°, 90°, 180°, 270° including Corridor Format,
aspect ratio correction, text and image overlay, privacy mask,
mirroring of images |
| Network |
| Security | Password protection, IP address filtering, HTTPSa
encryption,
IEEE 802.1Xa
network access control, digest authentication, user
access log
WPA/WPA2-PSK, WPA, WPA2 Enterprise, WLAN pairing button
(WPS) PBC-compatible,
Brute force delay protection |
| Supported
protocols | IPv4, IPv6 USGv6, HTTP, HTTPSa
, SSL/TLSa
, QoS Layer 3 DiffServ,
FTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMPv1/v2c/v3 (MIB-II),
DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP,
ARP, SOCKS, LLDP |
| General
|
| Casing | Polycarbonate blend
Color: White NCS S 1002-B and Axis Black NCS S9000-N |
| Mounting | ¼”-20 tripod screw thread
Camera stand included |
| Memory | 512 MB RAM, 256 MB Flash |
| Power | 8-28 V DC or Power over Ethernet (PoE) IEEE 802.3af Class 2,
max 5.0 W, typical 3.6 W |
| Connectors | Terminal block for one input and one output (12 V DC output,
max. load 15 mA)
DC input, terminal block |
| Storage | Support for microSD/microSDHC/microSDXC card
Support for recording to network-attached storage (NAS)
For SD card and NAS recommendations, see axis.com |
| Operating
conditions | -20 °C to 50 °C (-4 °F to 122 °F)
Humidity 10–85% RH (non-condensing)
|
| Approvals | EMC
EN 55022 Class A, EN 61000-6-1, EN 61000-3-2,
EN 61000-3-3, EN 61000-6-2, EN 55024, EN 50121-4,
FCC Part 15 Subpart B Class A, ICES-003 Class A, VCCI Class A,
RCM AS/NZS CISPR 22 Class A, KCC KN22 Class A, KN24
Safety
IEC/EN/UL 60950-1, IS 13252
Environment
EN 50581, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14,
IEC 60068-2-30, IEC 60068-2-78, IEC 60721-4-3 Class 3M4
Network
NIST SP500-267 |
| Storage
conditions | -40 °C to 65 °C (-40 °F to 149 °F)
Humidity 5–95% RH (non-condensing) |
| Dimensions | 240 x 143 x 372 mm (9.5 x 5.6 x 14.7 in) including wall mount |
| Weight | 1.8 kg (4.0 lb) including wall mount
|
| Included
accessories | AXIS T91A11 Stand White, Installation Guide, Windows®
decoder
1-user license |
| Optional
accessories | AXIS T91A04/T91A05 Camera Holders, AXIS T91A50 Telescopic
Ceiling Mount, AXIS T92E20 and AXIS T93F Housing Series,
Mains adaptor PS-P terminal connector, AXIS T8006 PS12,
AXIS T90B Illuminators |
| Video
management
software | AXIS Companion video management software,
AXIS Camera Station, Video management software
from Axis’ Application Development Partners available at
axis.com/vms |
| Languages | English, German, French, Spanish, Italian, Russian, Simplified
Chinese, Japanese, Korean, Portuguese, Traditional Chinese |
| Warranty | Axis 3-year warranty |
