CISCO Original 9200L Series 24 Port Gigabit Ethernet 4 x 1G Optical Fiber Network Switch C9200L-24T-4G-A C9200L-24T-4G-A is the Catalyst 9200L 24-port Data 4x1G uplink Switch with Network Advantage software.C9200L-24T-4G-E with Stackable 24x1G ports; 4x1G SFP fixed uplink ports; 2 power supply slots; 2 fixed fans; supports StackWise-80.
Part No.:
C9200L-24T-4G-A
Downlinks total 10/100/1000 or PoE+ copper ports
24 ports data
Uplink configuration
4x 1G fixed uplinks
Default primary AC power supply
PWR-C5-125WAC
Fans
Fixed redundant
Software
Network Advantage
Virtual Networks
1
Stacking bandwidth
80 Gbps
Total number of MAC addresses
16,000
Total number of IPv4 routes (ARP plus learned routes)
11,000 (8,000 direct routes and 3,000 indirect routes)
IPv4 routing entries
3,000
IPv6 routing entries
1,500
Multicast routing scale
1,000
QoS scale entries
1,000
ACL scale entries
1,500
Packet buffer per SKU
6 MB buffers for 24- or 48-port Gigabit Ethernet models
Flexible NetFlow (FNF) entries
16,000 flows on 24- and 48-port Gigabit Ethernet models
DRAM
2 GB
Flash
4 GB
VLAN IDs
1024
Total Switched Virtual Interfaces (SVIs)
512
Jumbo frames
9198 bytes
Wireless bandwidth per switch
N/A
Switching capacity
56 Gbps
Switch capacity with Stacking
136 Gbps
Forwarding rate
41.66 Mpps
