The Ruckus 901-H350-WW00 is a high-performance Wi-Fi 6 (802.11ax) indoor access point designed to deliver reliable, secure, and high-capacity wireless connectivity for enterprises, educational institutions, hospitality venues, healthcare facilities, retail environments, and other high-density deployment scenarios. Featuring advanced dual-band concurrent wireless technology, the H350 provides exceptional throughput, improved spectrum efficiency, and enhanced client capacity to support the growing number of mobile devices, IoT applications, cloud services, and bandwidth-intensive business operations. Powered by Ruckus' industry-leading BeamFlex+ adaptive antenna technology and ChannelFly dynamic channel management, the access point intelligently optimizes wireless coverage, minimizes interference, and maximizes network performance even in challenging RF environments. It supports multiple spatial streams, OFDMA, MU-MIMO, WPA3 wireless security, fast roaming, and advanced Quality of Service (QoS), ensuring seamless connectivity for voice, video conferencing, streaming, and mission-critical enterprise applications. The compact and modern design allows flexible wall or desktop installation, making it an excellent choice for hotel guest rooms, student dormitories, apartments, offices, and branch locations where both performance and aesthetics are important. The integrated Gigabit Ethernet uplink with Power over Ethernet (PoE) support simplifies deployment while reducing installation costs by eliminating the need for separate power supplies. Centralized management is available through Ruckus SmartZone, RUCKUS One, or Ruckus Unleashed platforms, enabling IT administrators to efficiently configure, monitor, troubleshoot, and scale wireless networks from a single interface. Enterprise-grade security features, including secure authentication, network segmentation, guest access management, and encrypted communications, help protect sensitive business data while ensuring compliance with modern network security standards. Designed for long-term reliability and continuous operation, the Ruckus 901-H350-WW00 offers outstanding wireless coverage, low latency, and stable performance, making it an ideal solution for organizations seeking to upgrade their existing WLAN infrastructure with next-generation Wi-Fi 6 technology. As an authorized supplier of original new Ruckus networking products, we provide competitive pricing, abundant inventory, fast worldwide shipping, professional technical support, and flexible logistics solutions to meet the needs of distributors, system integrators, resellers, enterprise customers, and global B2B and B2C buyers.
901-H350-WW00
Ruckus
Original New
1 year
| Quantity: | |
|---|---|
Item | Official Specification |
|---|---|
Model Number | 901-H350-WW00 |
Product Series | Ruckus H350 Wall-Mounted Indoor Access Point |
Product Type | Wi-Fi 6 Indoor AP with Integrated Ethernet Switch & Embedded IoT Gateway |
Target Application | Hospitality Hotel Guest Rooms, Student Dormitories, Multi-Dwelling Units (MDU), Small Office Networks, Retail In-Room Connectivity |
Wi-Fi Standard | IEEE 802.11a/b/g/n/ac/ax (Wi-Fi 6 Certified) |
Concurrent Users Support | Up to 512 simultaneous client devices |
Wireless Radio Type | Dual-Band (2.4GHz + 5GHz) Concurrent Radio |
MIMO Configuration | 2x2:2 SU-MIMO & MU-MIMO on both bands |
Maximum PHY Data Rate | 1774 Mbps (Combined) |
2.4GHz Band Max Rate | 574 Mbps (802.11ax) |
5GHz Band Max Rate | 1200 Mbps (802.11ax) |
Receive Sensitivity (2.4GHz) | -100 dBm |
Receive Sensitivity (5GHz) | -100 dBm |
Antenna Technology | Ruckus Patented BeamFlex+ Adaptive Antenna |
Antenna Patterns | 16 unique antenna patterns per band |
Antenna Gain | Up to 1 dBi |
Supported Wi-Fi Channels | 2.4GHz: 1-13; 5GHz: 36-64, 100-144, 149-165 (region-dependent) |
Wired Interfaces | 3 × 10/100/1000BASE-T Gigabit Ethernet Ports (1 Uplink + 2 Downlink Access Ports) |
USB Port | 1 × USB 2.0 Port |
IoT Connectivity | Onboard IoT Radio (Support for Bluetooth Low Energy (BLE) / Zigbee) |
Mesh Support | Ruckus SmartMesh Technology Enabled |
Channel Optimization | ChannelFly Dynamic Channel Selection |
Management Platforms | Ruckus Cloud™, Ruckus SmartZone™, Ruckus Unleashed™, Ruckus ZoneDirector™ |
Management Interfaces | Web UI, CLI, SNMP, SSH, Telnet |
Security Protocols | WPA3-Enterprise, WPA2-Enterprise, WPA-PSK, 802.1X Authentication, RADIUS/TACACS+ Support, Rogue AP Detection, DoS Attack Protection |
QoS Features | Wi-Fi Multimedia (WMM), 8 hardware queues per port, WRR + Strict Priority Scheduling |
Power Supply | 802.3af PoE Powered (No DC Power Adapter Included) |
Maximum Power Consumption | 12.54 W |
Transmit Power (2.4GHz) | 16 dBm per chain (2x2) |
Transmit Power (5GHz) | 19 dBm per chain (2x2) |
Physical Dimensions (W × L × H) | 89.5 mm × 178.5 mm × 29.3 mm (3.52 in × 7.03 in × 1.15 in) |
Net Weight | 276 g (0.608 lbs) without mounting bracket; 346 g (0.763 lbs) with bracket |
Mounting Options | Standard US/EU single gang electrical wallbox, optional offset/wall mount bracket |
Operating Temperature | 0°C to +40°C (+32°F to +104°F) |
Operating Humidity | Up to 95% non-condensing |
Storage Temperature | -25°C to +70°C (-13°F to +158°F) |
MTBF (25°C Ambient) | 1,000,000 hours |
Regulatory Certifications | Wi-Fi CERTIFIED 6™, Wi-Fi Alliance a/b/g/n/ac, FCC, CE, UL, CSA, RoHS Compliant |
Warranty | Ruckus Limited Lifetime Hardware Warranty |
