ARUBA 370EX SERIES
Aruba
New
1year
| Quantity: | |
|---|---|
Product Description
Product Details
| AP-370EX SERIES SPECIFICATIONS | •AP-375EX - 5GHz 802.11ac 4x4 MU-MIMO (1,733 Mbps max rate) - Internal Omni Antennas 4.6 dBi - 2.4 GHz 802.11n 2x2 MIMO (300 Mbps max rate) radios - Internal Omni Antennas 4.0 dBi •AP-377EX - 5GHz 802.11ac 4x4 MU-MIMO (1,733 Mbps max rate) - Internal 80°H x 80°V Directional Antennas 6.3 dBi - 2.4 GHz 802.11n 2x2 MIMO (300 Mbps max rate) radios - Internal 80°H x 80°V Directional Antennas 6.4 dBi |
| MOUNTING | •AP-270-MNT-V1 •AP-270-MNT-V2 •AP-270-MNT-H1 •AP-270-MNT-H2 |
| MECHANICAL | AP-375EX •Dimensions/weight (excluding mount): - 23 cm (W) x 24 cm (D) x 27 cm (H) - 9.0" (W) x 9.4" (D) x 10.6" (H) - 2.4 kg/5.3 lbs AP-377EX •Dimensions/weight (excluding mount): - 23 cm (W) x 22 cm (D) x 13 cm (H) - 9.0" (W) x 8.7" (D) x 5.1" (H) - 2.1 kg/4.6 lbs |
| ENVIRONMENTAL | •Operating: - Temperature: -40° C to +65° C (-40° F to +149° F) - Humidity: 5% to 95% noncondensing •Storage and transportation: - Temperature: -40° C to +70° C (-40° F to +158° F) •Operating Altitude: 3,000 m •Water and Dust - IP66/67 •Salt Tolerance - Tested to ASTM B117-07A Salt Spray 200hrs •Wind Survival: Up to 165 Mph •Shock and Vibration ETSI 300-19-2-4 |
| REGULATORY | •FCC/ISED •CE Marked •RED Directive 2014/53/EU •EMC Directive 2014/30/EU •Low Voltage Directive 2014/35/EU •UL/IEC/EN 60950 •EN 60601-1-1, EN60601-1-2 |
| Regulatory Model Number | •AP-375EX: APEX0375 •AP-377EX: APEX0377 |
| CERTIFICATIONS | •CB Scheme Safety, cTUVus •UL2043 plenum rating •Wi-Fi Alliance certified 802.11a/b/g/n •Wi-Fi CERTIFIED™ ac (with wave 2 features) •Passpoint® (Release 2) with ArubaOS and Instant 8.3+ |
| Minimum Operating System Software | •Limited Lifetime Warranty |
