Product Description
With the ever-growing number of IoT devices, demand for reliable connectivity is rising - not just in traditional carpeted enterprises but also in outdoor use cases such as enabling connectivity across buildings on the same campus, adjacent structures (e.g. parking garage or annex), and remote or temporary event sites.
Point-to-point wireless solutions offer an attractive option for connecting two sites together where the right of way is difficult to obtain - or as a backup or recovery link for existing connections. But legacy point-to-point solutions can be expensive and vulnerable to inclement weather conditions. They can also require highly skilled workers for AP installation and alignment.
KEY FEATURES
•Cost-effective and easy-to-deploy with automatic radio alignment
•High reliability with intelligent fallback to the 5GHz 802.11ac radio
•Up to 3.37 Gbps of aggregate throughput (60GHz: 2.5Gbps and 5GHz: 867Mbps)
•Up to 400 meters of extended range
•IoT-ready with integrated Bluetooth Low Energy (BLE)
•Based on a proven, hardened outdoor design
•Participates in Aruba's Dynamic Segmentation solution
Product Details
| AP-387 SPECIFICATIONS | |
| MOUNTING | •AP-270-MNT-V1 •AP-270-MNT-V2 •AP-270-MNT-H1* •AP-270-MNT-H2* |
| MECHANICAL | •Dimensions/weight (excluding mount adapter): - 18 cm (W) x 18 cm (D) x 10.1 cm (H) - 1.198 kg |
| ENVIRONMENTAL | •Operating: - Temperature: -40° C to +60° C (-40° F to +140° F) - Humidity: 5% to 95% non-condensing •Storage and transportation: - Temperature: -40° C to +70° C (-40° F to +158° F) •Operating Altitude: 3,000 m •Water and Dust - IP66/67 •Salt Tolerance - Tested to ASTM B117-07A Salt Spray 200hrs •Wind Survival: Up to 165 Mph •Shock and Vibration ETSI 300-19-2-4 |
| REGULATORY | •FCC/ISED •CE Marked •RED Directive 2014/53/EU •EMC Directive 2014/30/EU •Low Voltage Directive 2014/35/EU •UL/IEC/EN 60950 •EN 60601-1-1, EN60601-1-2 |
| Regulatory Model Number | AP-387: APEX0387 |
| CERTIFICATIONS | •CB Scheme Safety, cTUVus •UL2043 plenum rating •Wi-Fi Alliance certified 802.11a/b/g/n/ac |
| Minimum Operating System Software | •8.4. AOS and 8.4 for Instant |
