FG-200E
Fortinet
Original New
1 year
| Quantity: | |
|---|---|
FortiGate 200E
The FortiGate 200E series delivers next generation firewall (NGFW) capabilities for mid-sized to large enterprises deployed at the campus or enterprise branch level. Protects against cyber threats with high-powered security processors for optimized network performance, security efficacy and deep visibility. Fortinet's Security-Driven Networking approach provides tight integration of the network to the new generation of security.
FortiGate 200E
Interfaces
1. Console Port
2. USB Port
3. 2x GE RJ45 Management/HA Ports
4. 2x GE RJ45 WAN Ports
5. 14x GE RJ45 Ports
6. 4x GE SFP Slots
Product Specifications
| FortiGate 200E | |
| Hardware Specifications | |
| GE RJ45 WAN Interfaces | 2 |
| GE RJ45 Management/HA Ports | 2 |
| GE RJ45 Ports | 14 |
| GE SFP Slots | 4 |
| USB port | 1 |
| Console (RJ45) | 1 |
| Local Storage | - |
| Included Transceivers | 0 |
| System Performance - Enterprise Traffic Mix | |
| IPS Throughput 2 | 2.2 Gbps |
| NGFW Throughput 2, 4 | 1.8 Gbps |
| Threat Protection Throughput 2, 5 | 1.2 Gbps |
| System Performance | |
| Firewall Throughput | 20 / 20 / 9 Gbps |
| Firewall Latency (64 byte UDP packets) | 3 μs |
| Firewall Throughput (Packets Per Second) | 13.5 Mpps |
| Concurrent Sessions (TCP) | 2 Million |
| New Sessions/Second (TCP) | 135,000 |
| Firewall Policies | 10,000 |
| IPsec VPN Throughput (512 byte) | 9 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels | 2,000 |
| Client-to-Gateway IPsec VPN Tunnels | 10,000 |
| SSL-VPN Throughput | 900 Mbps |
| Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) | 300 |
| SSL Inspection Throughput (IPS, avg. HTTPS) 3 | 820 Mbps |
| SSL Inspection CPS (IPS, avg. HTTPS) 3 | 1,000 |
| SSL Inspection Concurrent Session (IPS, avg. HTTPS) 3 | 240,000 |
| Application Control Throughput (HTTP 64K) 2 | 3.5 Gbps |
| CAPWAP Throughput (HTTP 64K) | 1.5 Gbps |
| Virtual Domains (Default / Maximum) | 10 / 10 |
| Maximum Number of Switches Supported | 24 |
| Maximum Number of FortiAPs (Total / Tunnel Mode) | 128 / 64 |
| Maximum Number of FortiTokens | 1,000 |
| Maximum Number of Registered FortiClients | 600 |
| High Availability Configurations | Active / Active, Active / Passive, Clustering |
| Dimensions | |
| Height x Width x Length (inches) | 1.75 x 17.0 x 11.9 |
| Height x Width x Length (mm) | 44.45 x 432 x 301 |
| Weight | 11.9 lbs (5.4 kg) |
| Form Factor | Rack Mount, 1 RU |
| Environment | |
| Power Required | 100-240V AC, 50-60 Hz |
| Maximum Current | 110 V / 3 A, 220 V / 0.42 A |
| Power Consumption (Average / Maximum) | 70.98 / 109.9 W |
| Heat Dissipation | 374.9 BTU/h |
| Operating Temperature | 32-104°F (0-40°C) |
| Storage Temperature | -31-158°F (-35-70°C) |
| Operating Altitude | 32-104°F (0-40°C) |
| Humidity | 10-90% non-condensing |
| Noise Level | 31.1 dBA |
| Operating Altitude | Up to 7,400 ft (2,250 m) |
| Compliance | FCC Part 15B, Class A, CE, RCM, VCCI, UL/cUL, CB, BSMI |
| Certifications | ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; IPv6 |
