C1300-24T-4X
Cisco
Original New
1 year
| Quantity: | |
|---|---|
Category | Parameter | Specification |
|---|---|---|
Basic Information | Brand | Cisco |
Model Number | C1300-24T-4X | |
Product Series | Cisco Catalyst 1300 Series | |
Device Type | Layer 2 / Layer 3 Fully Managed Gigabit Ethernet Switch | |
Target Application | Small & Medium Businesses (SMB), Branch Offices, Enterprise Access Networks | |
Form Factor | 1U Rack-mountable Chassis | |
Port Configuration | 10/100/1000BASE-T RJ45 Ethernet Ports | 24 ports |
10G SFP+ Uplink Slots | 4 x Multi-rate SFP+ slots (support 1/2.5/5/10 Gbps fiber/copper transceivers) | |
Management Console Interfaces | 1 x USB-C Console Port + 1 x RJ45 Console Port | |
USB Port | 1 x USB-A Port (for file management, firmware upgrade) | |
Reset Button | 1 x Factory Reset Button | |
Performance Specifications | Switching Capacity | 128 Gbps |
Forwarding Rate (64-byte Packets) | 95.23 Mpps | |
Switching Architecture | Non-blocking, Wire-speed Forwarding | |
MAC Address Table Size | 16,000 entries | |
VLAN Support | Up to 4,094 VLANs (802.1Q Tagged) | |
Jumbo Frame Support | Up to 10,000 bytes | |
Packet Buffer | 1.5 MB | |
CPU | ARM Dual-core 1.4 GHz | |
DRAM | 1 GB DDR4 | |
Flash Memory | 512 MB | |
Core Network Features | Layer 2 Functions | 802.1Q VLAN, Voice VLAN, Guest VLAN; STP/RSTP/MSTP Loop Prevention; Link Aggregation (LACP 802.3ad); IGMP Snooping v1/v2/v3; Port Security, 802.1X Port Authentication; Storm Control (Broadcast/Multicast/Unicast); Port Mirroring (SPAN) |
Layer 3 Functions | Static IPv4/IPv6 Routing; Inter-VLAN Routing; DHCP Server / DHCP Snooping / DHCP Option 82; IPv4/IPv6 ACL Access Control List; Static Default Route Support | |
Stackable | Yes, supports true stacking capability (single IP management for stacked switches) | |
QoS & Security | QoS Features | 8 Hardware Priority Queues per Port; 802.1p CoS, DSCP Mapping, Traffic Shaping & Policing; Voice/Video/Data Traffic Priority Scheduling; Head-of-Line (HOL) Blocking Prevention |
Security Features | Web UI / CLI / SSH Secure Management; HTTPS, SNMPv3, RADIUS/TACACS+ Authentication; Port Isolation, DoS Attack Protection; Password Encryption, Configuration File Encryption; Firmware Integrity Verification; MAC Address Filtering, ARP Inspection | |
Physical & Mechanical Specifications | Dimensions (W × D × H) | 44.45 cm × 29.87 cm × 4.39 cm (1U Rack Height) |
Weight | 3.6 kg | |
Cooling Design | Fanless Silent Design | |
Mounting | Standard 19-inch Rack Mount Brackets Included | |
Cabling Type | Unshielded Twisted Pair (UTP) Category 5e or better for 1000BASE-T | |
LEDs | System, Link/Act, Speed Status Indicators | |
Power Supply | Input Power | AC 100–240V, 50/60Hz Internal Power Supply |
Power Plug Type | Type C | |
Max Total Power Consumption | 22.4W (220V) / 22.3W (110V) | |
Idle Power Consumption | 5.2W (220V) / 4.9W (110V) | |
Heat Dissipation | 76.4 BTU/hr | |
Environmental Requirements | Operating Temperature | 0°C to 50°C (32°F to 122°F) |
Storage Temperature | -25°C to 70°C (-13°F to 158°F) | |
Operating Humidity | 10%–90% Non-condensing | |
Altitude Limit | Up to 3,000 Meters Above Sea Level | |
Compliance & Standards | Industry Standards | IEEE 802.3, 802.3u, 802.3ab (Gigabit Ethernet); IEEE 802.3ae (10 Gigabit Ethernet); IEEE 802.1Q VLAN, 802.1p QoS; IEEE 802.1X Authentication, 802.3ad LACP |
Certifications | CE, FCC Class A, RoHS, UL Safety Certification | |
Warranty | Limited Lifetime Protection | |
Management Methods | Supported Management | Web-based Graphical User Interface (HTTP/HTTPS); Command Line Interface (CLI via USB-C / RJ45 Console); SNMP v1/v2c/v3; Cisco Business Dashboard Auto-discovery & Management; TFTP Firmware Upgrade & Config Backup/Restore |
Package Contents | In-box Items | 1 x Cisco Catalyst C1300-24T-4X Managed Switch; 1 x AC Power Cable; 1 x USB Type C Cable; 1 x Set of 19-inch Rack Mount Brackets & Mounting Hardware; 1 x Quick Start Guide |
