The MikroTik CCR2004-1G-12S+2XS is a high-performance Cloud Core Router designed for enterprise networks, data centers, ISPs, and demanding business environments that require exceptional routing capacity, high-speed connectivity, and reliable network performance. Powered by a powerful 64-bit ARM architecture CPU with four cores running at 1.7 GHz and equipped with 4 GB of DDR4 RAM and 128 MB NAND storage, this router delivers outstanding processing power for complex routing, VPN, firewall, MPLS, BGP, OSPF, VLAN, and advanced Layer 3 networking tasks. It features twelve 10G SFP+ ports, two 25G SFP28 ports, and one Gigabit Ethernet management port, providing flexible deployment options for high-density fiber aggregation, server connectivity, storage networks, enterprise backbones, and carrier-grade applications. Running MikroTik's feature-rich RouterOS, the CCR2004-1G-12S+2XS supports comprehensive networking functions including IPv4/IPv6 routing, dynamic routing protocols, QoS, traffic shaping, load balancing, link aggregation, VPN technologies such as IPsec, WireGuard, OpenVPN, and L2TP, advanced firewall security, bandwidth management, hotspot services, and centralized network management. Its dual 25G uplink interfaces significantly increase backbone bandwidth while ensuring seamless integration into modern high-speed network infrastructures. The compact 1U rackmount design allows easy installation in standard server racks, making it suitable for enterprise campuses, cloud service providers, internet service providers, financial institutions, educational organizations, government agencies, and large-scale commercial networks. Designed for continuous operation, the router offers excellent stability, low power consumption, efficient cooling, and dependable long-term performance even under heavy traffic loads. The CCR2004-1G-12S+2XS is an ideal solution for organizations seeking a cost-effective yet powerful routing platform capable of supporting high-speed fiber connectivity, virtualization environments, data center aggregation, and future network expansion. Its combination of outstanding throughput, extensive software features, enterprise-grade reliability, and scalable 10G/25G networking makes it one of the most versatile and valuable Cloud Core Routers in the MikroTik portfolio. As a professional global supplier of original MikroTik networking products, ImportGM provides genuine new devices, competitive pricing, sufficient inventory, fast worldwide shipping, professional technical support, and reliable after-sales service to help customers build secure, scalable, and high-performance network infrastructures.
CCR2004-1G-12S+2XS
Mikrotik
Original New
1 year
| Quantity: | |
|---|---|
=
Category | Parameter | Specification |
|---|---|---|
Basic Information | Model Name | CCR2004-1G-12S+2XS |
Product Series | MikroTik Cloud Core Router (CCR) 2004 Series | |
Architecture | ARM 64-bit | |
Form Factor | 1U Rack-mountable Chassis | |
MTBF | Approximately 200,000 hours at 25°C | |
CPU & Memory | CPU Model | AL32400 |
CPU Cores/Threads | 4 cores / 4 threads | |
CPU Nominal Frequency | 1700 MHz | |
RAM | 4 GB DDR4 ECC (RouterOS v7); 1792 MB ECC (RouterOS v6) | |
Storage | 128 MB NAND Flash | |
Port Configuration | Management Ethernet Port | 1 x 10/100/1000BASE-T RJ45 |
10G SFP+ Ports | 12 x SFP+ slots (support 1G/10G fiber/copper transceivers) | |
25G SFP28 Ports | 2 x SFP28 slots (support 25G transceivers) | |
Performance | IPsec Throughput | Up to 2.3 Gbps (single tunnel) |
BGP Feed Processing | High-performance single-core processing for full BGP feeds | |
Forwarding Capacity | Wire-speed forwarding for all ports (no CPU bottleneck for basic switching) | |
Power Supply | Input Voltage | AC 100–240 V, 50/60 Hz |
AC Inputs | 2 redundant AC power inputs | |
Max Power Consumption | 60 W (with attachments); 31 W (without attachments) | |
Cooling Type | 2 built-in fans | |
Physical & Environmental | Dimensions (W × D × H) | 443 mm × 224 mm × 44 mm (1U rack height) |
Operating Temperature | -20°C to +60°C (tested) | |
Storage Temperature | -40°C to +70°C | |
Operating Humidity | 10%–90% non-condensing | |
System & Licensing | Operating System | RouterOS v7 (pre-installed) |
Router License Level | Level 6 | |
Default Configuration | Default IP: 192.168.88.1; Default username: admin; No default password | |
Compliance & Included Parts | Regulatory Compliance | CE, FCC, RoHS, UL safety certifications |
Included Accessories | 2 x IEC power cords, rackmount brackets, mounting fastener set |
