The MikroTik CSS106-1G-4P-1S is a compact and cost-effective Ethernet switch designed for small office networks, home users, and simple network expansion projects. It features 1 Gigabit Ethernet port, 4 Fast Ethernet ports with PoE output capability, and 1 SFP port for fiber connectivity, providing flexible options for copper and fiber-based network deployments. Powered by the easy-to-use SwOS operating system, the CSS106-1G-4P-1S offers essential Layer 2 switching functions, including port-to-port forwarding, VLAN support, bandwidth limitation, MAC filtering, and traffic monitoring, allowing users to efficiently manage their network without complex configuration. The integrated PoE output on the Ethernet ports makes it an ideal solution for powering compatible devices such as IP cameras, wireless access points, and VoIP phones, helping reduce installation costs and simplify cabling. With its compact desktop design, low power consumption, reliable performance, and versatile connectivity options, the MikroTik CSS106-1G-4P-1S is a practical choice for small businesses, surveillance systems, SOHO environments, and network applications that require stable and affordable switching performance. As an original MikroTik network solution, it delivers excellent value for users looking for a reliable Gigabit switching device with PoE capability and fiber uplink support.
CSS106-1G-4P-1S
Mikrotik
Original New
1 year
| Quantity: | |
|---|---|
Item | Specification |
|---|---|
Product Model | CSS106‑1G‑4P‑1S |
Product Series | MikroTik Cloud Smart Switch |
CPU | Switch chip, no independent CPU |
Ports | 4 x Gigabit Ethernet PoE‑out RJ45 ports 1 x Gigabit Ethernet RJ45 uplink port 1 x SFP Gigabit fiber slot |
PoE Output | PoE‑out 802.3af/at on ports 1‑4 Total PoE budget: 60W |
Supported PoE Modes | 802.3af, 802.3at |
Switching Capacity | 12 Gbps |
Forwarding Rate | 8.9 Mpps |
VLAN | 802.1Q VLAN, Port‑based VLAN |
Management | Web‑UI, Smart switch function, RoMON support |
Mounting | Desktop, wall‑mountable |
Power Input | 24V‑57V DC power jack (power supply not included) |
Dimensions | 110 mm × 75 mm × 22 mm |
Operating Temperature | -10 °C to +60 °C |
Software | SwOS firmware |
Certifications | CE, FCC, RoHS |
