Cisco C9300L-24P-4X-E Catalyst 9300L 24-Port PoE+ 4X10G Uplinks Network Essentials Switch

Share to:

Cisco C9300L-24P-4X-E Catalyst 9300L 24-Port PoE+ 4X10G Uplinks Network Essentials Switch

Cisco Catalyst Cisco C9300L-24P-4X-E is a high-performance enterprise-class Layer 3 access switch designed for modern campus networks, delivering reliable scalability, advanced security, and superior operational efficiency for business-critical environments; it features 24 Gigabit Ethernet PoE+ ports that support high-power devices such as IP phones, wireless access points, and surveillance cameras, along with 4 fixed 10G SFP+ uplink interfaces to ensure high-speed aggregation and seamless backbone connectivity, making it ideal for enterprise edge and branch deployments; built on Cisco’s next-generation switching architecture, this model supports advanced features such as full Layer 3 routing, Cisco StackWise-480 technology for scalable stacking, enhanced Quality of Service (QoS), and robust security capabilities including TrustSec and MACsec encryption, helping organizations protect sensitive data and maintain network integrity; the C9300L series is optimized for cloud-managed and software-defined access (SD-Access) environments, enabling simplified network automation, policy-based segmentation, and improved visibility across the entire infrastructure; with its energy-efficient design, hot-swappable components, and high availability features, the C9300L-24P-4X-E ensures minimal downtime and long-term operational stability, making it a cost-effective yet powerful solution for enterprises, data centers, and large-scale campus deployments seeking reliable performance, flexible expansion, and future-ready networking capabilities in a single compact platform.

Model:
C9300L-24P-4X-E
Brand:
Cisco
Condition:
Original New
Warranty:
1 year

Availability:

Quantity:



Inquire Add to Basket

Item	Official Specification
Model Number	C9300L-24P-4X-E
Product Series	Cisco Catalyst 9300L Stackable Enterprise Switch
Built-in License	Network Essentials
Primary Application	Enterprise Office Access, Wi-Fi 6/6E AP Deployment, IP Phone & IP Camera Networks, SMB Branch Distribution Layer
Downlink Ports	24 × 10/100/1000BASE-T RJ45, all PoE+ compliant
Fixed Uplink Interfaces	4 × 10G SFP+ ports (support 10G/1G transceivers)
PoE Standards	IEEE 802.3af (15.4W/port), IEEE 802.3at PoE+ (30W/port)
Total PoE Power Budget	505W
Default Power Supply	Single PWR-C1-715WAC-P 715W AC power supply
Stacking Technology	StackWise-320, up to 8 switches in one logical stack, 320Gbps stacking bandwidth
Switching Capacity	128 Gbps
64-byte Packet Forwarding Rate	95.23 Mpps
Packet Buffer Memory	16 MB shared buffer
MAC Address Table	32,000 MAC entries
Routing Table Scale	32,000 IPv4 routes, 16,000 IPv6 routes
Jumbo Frame Support	Up to 9000 bytes
QoS Capability	8 hardware queues per port, strict priority + WRR scheduling, 5120 QoS entries
VLAN Support	Max 4094 VLANs, 802.1Q tagging, Voice VLAN, Guest VLAN
Spanning Tree Protocols	STP, RSTP, MSTP, PVST+, RPVST+
Link Aggregation	IEEE 802.3ad LACP, maximum 8 LAG groups
Multicast Functions	IGMP Snooping v1/v2/v3, PIM, Multicast replication
Port Features	Port mirroring, port isolation, rate limiting, broadcast/unicast/multicast storm control
Layer 3 Functions	Static IPv4/IPv6 routing, DHCP Snooping, DHCP Relay
Security Features	802.1X authentication, RADIUS/TACACS+, DoS protection, port security, ARP Guard, rogue DHCP suppression, SSH/HTTPS encrypted management, ACL (5120 entries)
Management Interfaces	RJ45 Console, USB-C Console, USB 3.0, MGMT Ethernet port, IOS XE, Cisco DNA Center compatible
Cooling System	Hot-swappable variable-speed fan modules
Physical Dimensions (H × W × D)	4.4 cm × 44.5 cm × 48.8 cm (1.73 in × 17.5 in × 19.2 in), 1U rackmount
Net Weight	7.13 kg (15.72 lbs)
Input Power Range	100–240V AC, 50/60Hz universal input
Operating Temperature	-5°C ~ 45°C, 5%–90% non-condensing humidity
Storage Temperature	-40°C ~ 70°C, 5%–90% non-condensing humidity
MTBF (25°C Ambient)	1,420,000 hours
Installation	Standard 19-inch rack mount
Regulatory Certifications	CE, FCC Class A, UL, CSA, RoHS Compliant
