The Cisco C1300-24XT is a high-performance managed Ethernet switch designed for small and medium-sized businesses, enterprise branch offices, and growing network infrastructures. Featuring 24 Multi-Gigabit Ethernet ports, it delivers reliable high-speed connectivity for bandwidth-intensive applications such as Wi-Fi 6/6E access points, IP surveillance, VoIP communications, cloud services, and high-performance workstations.
Built as part of the Cisco Catalyst 1300 Series, the C1300-24XT combines enterprise-class performance with simplified management, advanced Layer 2 capabilities, Layer 3 static routing, robust security features, and energy-efficient operation. Its flexible deployment options make it an ideal choice for modern business networks requiring scalable, secure, and dependable connectivity.
Supporting advanced Quality of Service (QoS), VLAN segmentation, Link Aggregation (LACP), Access Control Lists (ACLs), IPv4/IPv6 dual-stack operation, and comprehensive network management, the Cisco C1300-24XT helps optimize network performance while ensuring secure and stable data transmission. The switch can be easily integrated into existing infrastructures, making network expansion and maintenance straightforward.
Engineered for continuous business operation, the Cisco C1300-24XT offers excellent reliability, low latency, and efficient traffic management, enabling organizations to build future-ready networks that support digital transformation and increasing bandwidth demands.
Whether deployed in enterprise offices, educational institutions, healthcare facilities, retail environments, or hospitality networks, the Cisco C1300-24XT provides a cost-effective, secure, and scalable switching solution backed by Cisco's proven networking technology and long-term reliability.
C1300-24XT
Cisco
Original New
1 year
| Quantity: | |
|---|---|
Item | Official Specification |
|---|---|
Model Number | C1300-24XT |
Product Series | Cisco Catalyst 1300 Layer 3 Managed 10G Switch |
Application Scenarios | SMB Core Networks, Server Rack Interconnection, 10G Wi-Fi AP Backhaul, High-Speed Video Surveillance, Small Datacenter Access |
Warranty | Cisco Limited Lifetime Hardware Warranty |
Management Ports | RJ45 Console, USB-C Console, USB-A Port, Web UI, CLI, Cisco Business Dashboard, Cisco Business Mobile App |
Stacking Support | Front-panel hardware stacking, up to 8 switches in one logical unit |
Port Configuration | 20 × 10GBASE-T RJ45 copper ports (non-PoE) 4 × 10G Combo ports (shared RJ45 / SFP+) |
Supported Transceivers | 10G SFP+ SR, LR, ER, ZR, 10GBASE-T copper SFP+ modules |
PoE Support | No PoE power output |
Switching Bandwidth | 480 Gbps |
64-byte Packet Forwarding Rate | 357.14 Mpps |
MAC Address Table | 16,000 MAC entries |
Shared Packet Buffer | 8 MB |
Jumbo Frame | Up to 9000 bytes |
QoS Queues | 8 hardware queues per port, WRR + strict priority scheduling |
VLAN Capacity | Max 4093 802.1Q VLANs, Voice VLAN, Guest VLAN |
Spanning Tree Protocols | STP, RSTP, MSTP, PVST+, RPVST+ |
Link Aggregation | IEEE 802.3ad LACP, up to 8 LAG groups |
Multicast Functions | IGMP Snooping v1/v2/v3, multicast replication, storm control |
Port Features | Port mirroring, port isolation, port rate limiting, broadcast/multicast/unicast suppression |
Layer 3 Routing | IPv4 & IPv6 static routing, up to 990 IPv4 static routes, DHCP Snooping, DHCP Relay |
Security Features | 802.1X authentication, Web Auth, RADIUS/TACACS+, DoS protection, port security, ARP guard, SSH/HTTPS encrypted management, rogue DHCP block |
Cooling System | Variable-speed fan cooling |
Physical Dimension (W × D × H) | 445 mm × 350 mm × 44 mm (17.5 × 13.78 × 1.73 in), 1U standard rack mount |
Net Weight | 6.35 kg (14.0 lbs) |
Power Supply | Built-in universal AC power, 100–240V, 50/60Hz |
Idle Power Consumption | 36.5 W |
Max Full Load Power Consumption | 88 W |
Operating Environment | 0°C ~ 40°C ambient temperature, 10%–90% non-condensing humidity |
Storage Temperature | -25°C ~ 70°C, 10%–90% non-condensing humidity |
MTBF (25°C) | 1,420,000 hours |
Installation Options | 19-inch rack mount, desktop placement |
Regulatory Certifications | CE, FCC, UL, CSA, RoHS Compliant |
