CP-8800-A-KEM
original new
1 year
| Quantity: | |
|---|---|
The primary function of the 8800 KEM is to provide additional keys for directory numbers, speed dial, or programmable feature keys to the IP Phone 8851, 8861, and 8865 models. These keys are illuminated, and when configured as directory numbers or shared-line keys they allow for easy identification of line status. The 8800 KEM is an ideal call-coverage tool. It provides features that are similar, but not intended to be directly comparable to those of traditional direct station selection/busy lamp field (DSS/BLF) modules; therefore, it is neither an operator nor an attendant console.
Configuration options
| Sleep or inactivity mode | When Cisco IP Phone 8851, 8861, and 8865 models are in power-saving sleep or inactivity mode, the Cisco IP Phone 8800 KEM is also in sleep or inactivity mode. Pressing any button on the key expansion module causes the display to awaken. The system administrator configures the inactivity period. |
| Physical dimensions (H x W x D) | 9.02 x 5.15 x 1.58 in. (229.14 x 130.78 x 40.2 mm) |
| Weight | 1.08 lb (489g) |
| Power | 48 VDC, 117 mA maximum |
| Operating temperature | 32 to 104°F (0 to 40°C) |
| Relative humidity | 10 to 95% |
| Storage temperature | 12 to 140°F (-10 to 60°C) |
| Red, steady | Line in use by shared line |
The primary function of the 8800 KEM is to provide additional keys for directory numbers, speed dial, or programmable feature keys to the IP Phone 8851, 8861, and 8865 models. These keys are illuminated, and when configured as directory numbers or shared-line keys they allow for easy identification of line status. The 8800 KEM is an ideal call-coverage tool. It provides features that are similar, but not intended to be directly comparable to those of traditional direct station selection/busy lamp field (DSS/BLF) modules; therefore, it is neither an operator nor an attendant console.
Configuration options
| Sleep or inactivity mode | When Cisco IP Phone 8851, 8861, and 8865 models are in power-saving sleep or inactivity mode, the Cisco IP Phone 8800 KEM is also in sleep or inactivity mode. Pressing any button on the key expansion module causes the display to awaken. The system administrator configures the inactivity period. |
| Physical dimensions (H x W x D) | 9.02 x 5.15 x 1.58 in. (229.14 x 130.78 x 40.2 mm) |
| Weight | 1.08 lb (489g) |
| Power | 48 VDC, 117 mA maximum |
| Operating temperature | 32 to 104°F (0 to 40°C) |
| Relative humidity | 10 to 95% |
| Storage temperature | 12 to 140°F (-10 to 60°C) |
| Red, steady | Line in use by shared line |
