WS-C2960G-48TC-L
cisco
2-3 days
cisco original new in box
90 days
| Quantity: | |
|---|---|
Overview(WS-C2960G-48TC-L)
2960 Series Switches with LAN Base software are a family of fixed-configuration, standalone intelligent Ethernet devices that provide desktop Fast Ethernet and Gigabit Ethernet connectivity, enabling enhanced LAN services for entry-level enterprise, midmarket, and branch office networks. The Cisco Catalyst 2960 LAN Base Series offers integrated security, including Network Admission Control (NAC), advanced Quality of Service (QoS), and resiliency to deliver intelligent services for the network edge.
| Technical Specifications | |
| Device Type | Switch - 48 ports - managed |
| Enclosure Type | Desktop |
| Subtype | Gigabit Ethernet |
| Ports | 48 x 10/100/1000 + 8 x combo Gigabit SFP |
| MAC Address Table Size | 8K entries |
| Remote Management Proto | SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH |
| Authentication Method | RADIUS, TACACS+, Secure Shell v.2 (SSH2) |
| Features | Layer 2 switching, auto-sensing per device, dynamic IP address assignment, auto-negotiation, BOOTP support, ARP support, load balancing, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, DiffServ support, Broadcast Storm Control, IPv6 support, Multicast Storm Control, Unicast Storm Control, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Dynamic Trunking Protocol (DTP) support, Port Aggregation Protocol(PAgP) support, Access Control List (ACL) support, Quality of Service (QoS), Link Aggregation Control Protocol (LACP), Port Security, MAC Address Notification, Remote Switch Port Analyzer (RSPAN) |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ab (LLDP) |
| RAM | 64 MB |
| Flash Memory | 32 MB flash |
| Status Indicators | Port transmission speed, port duplex mode, power, link OK, system, link/activity |
| Expansion / Connectivity | |
| Interfaces | 48 x 1000Base-T RJ-45 ¦ 8 x SFP |
| Power | |
| Power Device | Internal power supply |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Opera | 72 Watt |
| Miscellaneous | |
| Compliant Standards | TUV GS, cUL, EN 60950, EN55022, NOM, VCCI Class A ITE, IEC 60950, EN55024, FCC Part 15, UL 1950 Third Edition, CSA 22.2 No. 950 Third Edition |
| Pricing Type | Used |
| Dimensions & Weight | |
| Width | 17.5 in |
| Depth | 12.9 in |
| Height | 1.7 in |
| Weight | 10.01 lbs |
