Fanvil H2U Compact IP Phone

The Fanvil H2U possesses brand new features including 2 SIP lines, 10 speed dial keys, 1 programmable DSS key and a HD speaker on handset. Supporting desktop and wall-mounted mode, PoE and power supply charging mode, Fanvil H2U is more than a hotel phone and also can be applied in multiple scenarios, such as school, hospital, supermarket and residence.

Fanvil H2U Key Features

2 SIP Lines
HD Audio with wideband Codec: G.722, Opus
10 speed dial keys, 1 programmable DSS Key
3-way Conference
Desk/wall-mounted mode
Handset / Hands-free mode
10/100 Mbps
PoE/Power adaptor
Exquisite and fashionable product appearance
Easy installation and configuration
Economical and Environmental friendly product concepts
Can store 10 shortcut numbers, long press to achieve speed dial
Adaptive 10/100Mbps network port, support POE power supply
Compatible with major platforms: Asterisk, Broadsoft, 3CX, Metaswitch, Elastix, Avaya etc.

Considerate Design for Varied Scenarios
Tiny and fully-featured, Fanvil H2U supports PoE/power supply charging as well as desktop/wall-mounted mode,
which can be applied in different scenarios flexibly.

Customisable Keys, One-click Communication
10 speed dial keys to customise different services, 1 programmable DSS keys for different functions and speed dial list.

Support SIP Hotspot
Fanvil H2U IP phones can share one number from the server. When a call comes in, each extension phone will ring together to make sure you won’t miss a call.

Fanvil H2U - Technical Specifications

Generic

2 SIP Lines
HD Voice
PoE Enabled
Handset / Hands-free mode
Intelligent DSS Keys
Desktop/wall mount mode
Optional External Power Supply

Phone Functions

Call logs (In/Out/Missed, Max support 600 records in the web)
Programmable DSS
Action URL / Active URI
Web dial

Call Functions

Call out / Answer
Mute / Unmute
Hands-free / Cancel hands-free
Call Hold / Resume
Speed Dial
Redial
Auto-Answering
3-way Conference
Hot Line
Hot desking

Audio

Narrowband Codec: G.711a/u, G.726, G.729A, iLBC
Wideband Codec: G.722, Opus
Acoustic Echo Canceller (AEC)
Voice Activity Detection (VAD) / Comfort Noise Generation (CNG) / Background Noise Estimation (BNE) / Noise Reduction (NR)
Packet Loss Concealment (PLC)
Dynamic Adaptive Jitter Buffer
DTMF: In-band, Out-of-Band – DTMF-Relay(RFC2833) / SIP INFO

Protocols

SIP2.0 over UDP/TCP/TLS
RTP/RTCP/SRTP
STUN
DHCP
IPv6
LLDP
PPPoE
802.1x
L2TP
OpenVPN
SNTP
FTP/TFTP
HTTP/HTTPS
TR-069

Deployment & Management

Auto-Provisioning via FTP/TFTP/HTTP/HTTPS/DHCP OPT66/SIP PNP/TR-069
Web Management Portal
Web-based Packet Dump
Configuration Export / Import
Firmware Upgrade
Syslog

Physical Specifications

Keypad: 19 keys, including:
- 12 Standard Phone Digits keys(0-9: Speed dial configuration on webpage)
- 3 Function keys (Hands-free , Redial ,Hold)
- 3 Volume Control keys, Up/Down/Mute(with red colour LED)
- 1 DSS key
Status indicator (two-colour LED) x1
HD Handset (RJ11) x1
Standard RJ11 Handset Cord x1
RJ11 Port x1
RJ45 Port x1
Power: 5V/2A or PoE
Power Consumption(PoE): 1.58W~3.47W
Power Consumption(Adapter): 0.87~2.23W
Working Temperature: 0~45°C
Working Humidity: 10~90%
Installation: Desktop/wall mount
Colour: Black/white
