X7C
Fanvil
100% Original Brand
1 Year
| Color: | |
|---|---|
| Size: | |
| Quantity: | |
Fanvil X7C-V2 is an enterprise IP phone for business users. Featuring 20 SIP lines, intelligent DSS key corresponding display screen, up to 60 DSS keys, bluetooth and WiFi connectivity, the X7C is the ideal communication tool to promote efficiency in any workplace.
Fanvil X7C Key Features
20 SIP lines
5" high-resolution colour display
HD audio on speakerphone and handset
Up to 60 DSS keys entries available (12 physical)
Built-in Bluetooth for connecting Bluetooth headset
Wi-Fi connectivity (via Wi-Fi dongle)
The Fanvil X7C High-end IP Phone features a Rich Extension Function
The X7C offers a variety of device connections including WiFi, built-in Bluetooth, EHS headset, USB connection for charging smartphone or other devices. Two Gigabit ports allows you to connect your desktop computer or laptop on the phone with no need for extra cabling.
.jpg "Rich extenstion function")
5" Capacitive Colour Display
The telephone's 5" large colour display offers convenient access to all key information such as call lists, phonebook, functions.
20 SIP Lines
HD Voice
Support receiving Video call
POE Enabled
5 Inch Colour LCD Screen
Handset / Hands-free / Headset mode
Intelligent DSS Keys
Optional External Power Supply
Call out / Answer / Reject
Mute / Unmute (microphone)
Call Hold / Resume
Call Waiting
Intercom
Caller ID Display
Speed Dial
Anonymous Call (Hide Caller ID)
Call Forwarding (Always/Busy/No Answer)
Call Transfer (Attended/Unattended)
Call Parking/Pick-up (depending on server)
Redial
Do-Not-Disturb
Auto-Answering
Voice Message (on server)
3-way Conference
Hot Line
Hot desking
Local Phonebook (2000 entries)
Remote Phonebook (XML/LDAP, 2000 entries)
Call logs (in/out/missed, 1000 entries)
Black/White List Call Filtering
Screen saver
Voice Message Waiting Indication (VMWI)
Programmable DSS/Soft keys
Network Time Synchronisation
Built-in Bluetooth 2.1: Support Bluetooth headset
Support Wi-Fi Dongle
Support Plantronics wireless headset (Through Plantronics APD-80 EHS Cable)
Support Jabra wireless headset (Through Fanvil EHS20 EHS Cable
Support Recording (Through Flash Drive or Server Recording )
Action URL / Active URI
uaCSTA
Video codec: H.264
Video call resolution: QCIF / CIF / VGA
HD Voice Microphone/Speaker (Handset/Hands-free, 0 ~ 7KHz Frequency Response)
HAC handset
Wideband ADC/DAC 16KHz Sampling
Narrowband CODEC: G.711a/u, G.723.1, G.726-32K, G.729AB, AMR, iLBC
Wideband CODEC: G.722, AMR-WB, Opus
Full-duplex Acoustic Echo Canceller (AEC)
Voice Activity Detection (VAD) / Comfort Noise Generation (CNG) / Background Noise Estimation (BNE) / Noise Reduction (NR
Packet Loss Concealment (PLC)
Dynamic Adaptive Jitter Buffer up to 300ms
DTMF: In-band, Out-of-Band – DTMF-Relay(RFC2833) / SIP INFO
Physical: 10/100/1000 Mbps Ethernet, dual bridged port for PC bypas
IP Mode:IPv4/IPv6/IPv4&IPv6
IP Configuration: Static / DHCP / PPPoE
Network Access Control: 802.1x
VPN: L2TP / OpenVPN
VLAN
LLDP
QoS
RTCP-XR(RFC3611),VQ-RTCPXR(RFC6035)
SIP2.0 over UDP/TCP/TLS
RTP/RTCP/SRTP
STUN
DHCP
IPv6
LLDP
PPPoE
802.1x
L2TP
OpenVPN
SNTP
FTP/TFTP
HTTP/HTTPS
TR-069
Auto-Provisioning via FTP/TFTP/HTTP/HTTPS/DHCP OPT66/SIP
PNP/TR-069
Web-based Packet Dump
Web management Portal
Configuration Export / Import
Phonebook Import/Export
Firmware Upgrade
Syslog
Main LCD x1:5.0 inch (800x480) color-screen LCD
Keypad: 43 keys, including
4 Soft-keys
12 DSS Keys with tri-color LED
1 Page-Switch (PS) key
5 Function keys (Hold, MWI,Mute,Headset, Redial)
4 Navigation keys
1 OK key
1 Return key
12 Standard Phone Digits keys
2 Volume Control keys, Up/Down
1 Hands-free key
HD Handset (RJ9) x1
Standard RJ9 Handset Wire x1
1.5M CAT5 Ethernet Cable x1
Back Rack x1
RJ9 Port x2: Handset x1, Headset x1
RJ45 Port x2: Network x1, PC x1 (Bridged to Network)
USB2.0 Port x1: Standard A, Connect with Wi-Fi USB dongle or Flash Driver
DC Power Input: 5V/2A
Power Consumption (POE): 2.6~9W
Power Consumption (Adapter): 2.4~8W
Working Temperature: 0~40℃
Working Humidity: 10~95%
Installation: Desktop Stand
Color: Black
