FG-60E
Fortinet
Original New
1 year
| Quantity: | |
|---|---|
FortiGate 60E
The FortiGate/FortiWiFi 60E series provides a fast and secure SD-WAN solution in a compact fanless desktop form factor for enterprise branch offices and mid-sized businesses. Protects against cyber threats with system-on-a-chip acceleration and industry-leading secure SD-WAN in a simple, affordable, and easy to deploy solution. Fortinet's Security-Driven Networking approach provides tight integration of the network to the new generation of security.
FortiGate 60E
Product Specifications
| FortiGate 60E | |
| Hardware Specifications | |
| GE RJ45 Switch Ports | 4 |
| GE RJ45 WAN Port | 1 |
| USB Port | 1 |
| Console (RJ45) | 1 |
| System Performance — Enterprise Traffic Mix | |
| IPS Throughput | 300 Mbps |
| NGFW Throughput | 200 Mbps |
| Threat Protection Throughput | 150 Mbps |
| System Performance | |
| Firewall Throughput | 950 Mbps |
| Firewall Latency (64 byte UDP packets) | 130 μs |
| Firewall Throughput (Packets Per Second) | 180 Kpps |
| Concurrent Sessions (TCP) | 900,000 |
| New Sessions/Second (TCP) | 15,000 |
| Firewall Policies | 5,000 |
| IPsec VPN Throughput (512 byte) | 75 Mbps |
| Gateway-to-Gateway IPsec VPN Tunnels | 200 |
| Client-to-Gateway IPsec VPN Tunnels | 250 |
| SSL-VPN Throughput | 35 Mbps |
| Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) | 100 |
| SSL Inspection Throughput (IPS, avg. HTTPS) | 125 Mbps |
| SSL Inspection CPS (IPS, avg. HTTPS) | 120 |
| SSL Inspection Concurrent Session (IPS, avg. HTTPS) | 45,000 |
| Application Control Throughput (HTTP 64K) | 400 Mbps |
| CAPWAP Throughput (HTTP 64K) | 850 Mbps |
| Virtual Domains (Default / Maximum) | 5 / 5 |
| Maximum Number of FortiSwitches Supported | 8 |
| Maximum Number of FortiAPs (Total / Tunnel Mode) | 2 / 2 |
| Maximum Number of FortiTokens | 500 |
| High Availability Configurations | Active/Active, Active/Passive, Clustering |
| Dimensions | |
| Height x Width x Length (inches) | 1.61 x 8.27 x 5.24 |
| Height x Width x Length (mm) | 41 x 210 x 133 |
| Weight | 1.982 lbs (0.899 kg) |
| Form Factor | Desktop |
| Environment | |
| Input Rating | 12Vdc, 2A |
| Power Required | Powered by External DC Power Adapter, 100–240V AC, 50–60 Hz |
| Maximum Current | 100V / 0.6A, 240V / 0.4A |
| Power Consumption (Average / Maximum) | 13 / 15 W |
| Heat Dissipation | 52 BTU/h |
| Operating Temperature | 32–104°F (0–40°C) |
| Storage Temperature | -31–158°F (-35–70°C) |
| Humidity | 10–90% non-condensing |
| Noise Level | Fan-less 0 dBA |
| Operating Altitude | Up to 7,400 ft (2,250 m) |
| Compliance | |
| Regulatory Compliance | FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB |
