Weight

2.03kg

Dimensions (W × D × H)

260 mm × 260 mm × 84 mm

Interface

1 x 100/1000M/2.5G/5G/10G Multigigabit Ethernet, RJ-45, PoE input

1 x 1000M/10G optical port, PSFP, PoE input

1 x 10/100/1000M Ethernet, RJ-45, PoE output

Console port

1 × Management console port (RJ-45)

USB port

1(2.0) at 2.5W

PoE input

1 x 100/1000M/2.5G/5G/10G Multigigabit Ethernet, 802.3bt/at

1 x 1000M/10G optical port, 802.3bt/at

PoE output

1 x 10/100/1000M Ethernet, 802.3af

Local power supply

POE injector

Antenna Type

Built-in omni-directional antenna

Antenna Gain

6GHz peak gain: 7.3dBi

5GHz peak gain: 7.2dBi

2.4GHz peak gain: 6.8dBi

Note: The equivalent antenna gain is 4.7dBi in 6GHz, 4.3dBi in 5GHz and 4.0dBi in 2.4GHz

Built-in IoT Module

BLE5.4

Frequencybands

2.400to2.4835GHzISM
5.150to5.250GHzU-NII-1
5.250to5.350GHzU-NII-2A
5.470to5.725GHzU-NII-2C
5.725to5.850GHzU-NII-3/ISM
5.925to6.425GHzU-NII-5
6.425to6.525GHzU-NII-6
6.525to6.875GHzU-NII-7
6.875to7.125GHzU-NII-8

Note: The available bands and channels are dependent on the configured regulatory domain (country)

Modulation technology

OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps

DSSS: DBPSK@1Mbps, DQPSK@2Mbps, CCK@5.5/11Mbps

Modulation mode

11b: DSSS: CCK@5.5/11Mbps, DQPSK@2Mbps, DBPSK@1Mbps

11a/g: OFDM: 64QAM@48/54Mbps, 16QAM@24Mbps, QPSK@12/18Mbps, BPSK@6/9Mbps

11n: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM

11ac: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM

11ax: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM

11be: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM, 4096QAM

Maximum transmit power

6G: 27 dBm

5G: 27 dBm

2.4G: 30 dBm

Note: Transmit power is multi-chain combined power, no antenna gain is included. The actual transmit power depends on local laws and regulations

Adjustable power granularity

1 dBm

Reset/restoration to factory default

support

Kensington Lock

support

Installation

wall-mounted / pole-mounted

Note: Mounting bracket not included by default

LED

Alternating flashing mode, yellow/green/blue for different working states

Temperature

Operating temperature: –40°C to +65°C

Storage temperature: –40°C to +80°C

Note: The value may vary depending on the installation environment.

Humidity

Operating humidity: 0% to 100% (non-condensing)

Storage humidity: 0% to 100% (non-condensing)

Protection class

IP68

Overall power consumption

Power Source

6GHz MIMO

5GHz MIMO

2.4GHz MIMO

Link speed

PSE

power consumption

802.3bt

2*2

2*2

2*2

10Gbps

Y

43W

802.3at

2*2

2*2

1*1

10Gbps

N

24.4W

802.3af

-

-

-

-

-

-

POE injector

2*2

2*2

2*2

10Gbps

N

28W

POE injector

2*2

2*2

2*2

10Gbps

Y

43W

Safety Standards

IEC/EN 62368-1

GB 4943.1

EMC Standards

EN 301 489-1

EN 301 489-3

EN 301 489-17

EN 60601-1-2

EN 55032

EN 55035

CISPR 32

CISPR 35

AS/NZS CISPR32

ICES-003 Issue 7

GB/T 9254.1

GB/T 9254.2

GB 17625.1

GB 17625.2

IEC/EN 61000-4-2

IEC/EN 61000-4-3

IEC/EN 61000-4-4

IEC/EN 61000-4-5

IEC/EN 61000-4-6

IEC/EN 61000-4-8

IEC/EN 61000-4-11

IEC/EN 61000-3-2

IEC/EN 61000-3-3

Radio Standards

ETSI EN 300 328

ETSI EN 301 893, FCC Part 15E, ETSI EN 300 440

ETSI EN 303 687

RoHS Standards

DIRECTIVE 2011/65/EU

(EU) 2015/863

Health Standards

EN 50385:2017

EN IEC 62311:2020

MTBF (25°C)

474203 hours
