Hot Sale Cisco Poe Switch 24 Ports WS-C2960XR-24PS-I Gigabit Ethernet PoE Switch

Catalyst 2960-XR 24 GigE PoE 370W, 4 x 1G SFP, IP Lite
  • WS-C2960XR-24PS-I

  • Cisco

  • 2-3 days

  • cisco original new in box

  • 1 year

Availability:
Quantity:

WS-C2960XR-24PS-I

FlexStack-Plus stacking for Catalys t 2960-XR series switch provides a true stacking solution, with all switches in a
FlexStack-Plus stack acting as a single switching unit. FlexStack-Plus provides a unified data plane and single configuration for a group of stacked Catalys t 2960-XR switch.FlexStack-Plus lower the total cost of ownership with built-in 1: N redundancy, high availability, and preprovisioning, not available in standalone switches. High-availability features such as EtherChannel and FlexLinks will work across stack members, increasing uptime and network connectivity.FlexStack-Plus is an improvement over FlexStack because it doubles the speed of the stack bandwidth and allows for more members to join the stack. The FlexStack-Plus bandwidth for a single stack member is 40 Gbps compared to 20 Gbps with FlexStack. With multiple stack members, the FlexStack-Plus bandwidth is 80 Gbps. With FlexStack-Plus technology, eight 2960-XR members can be joined into a single stack.

Technical Specifications
Type
Virtual interfaces (VLANs)
Value
1023
Dimensions & Weight
Width
17.5 in
Depth
16.1 in
Height
1.8 in
Weight
13.67 lbs
Interface Provided
Interface
Ethernet 10Base-T/100Base-TX/1000Base-T
Qty
4
Type
Mini-USB
Connector Type
Type B
Comments
Management
PoE Power
30 W
Authentication Method
Kerberos, RADIUS, Secure Shell (SSH), TACACS+
MTBF
321,290 hours
Status Indicators
Link/activity, PoE, Port duplex mode, Port status, Port transmission speed, RPS (Redundant Power Supply), System
Stackable
Stackable
Max Units In A Stack
8
Subcategory
Network hubs and switches
Form Factor
Desktop, Rack-mountable
Jumbo Frame Support
9216 bytes
Subtype
Gigabit Ethernet
PoE Budget
370 W
Performance
Type
Switching capacity
Value
216 Gbps
Qty
24
Type
10/100/1000 (PoE+)
Ports (2nd)
Qty
4
Type
Gigabit SFP
Power Device
Frequency Required
50/60 Hz
Power Provided
640 Watt
Installed Qty
1
Max Supported Qty
2
Nominal Voltage
AC 120/230 V
Features
Redundant Power System (RPS) connector
Power Redundancy
Optional
Power Redundancy Scheme
1+1 (with optional power supply)
Type
Internal power supply
Slot Provided
Type
Stacking Module slot
Total Qty
1
Free Qty
1
