Airengine5762S-12SW (11ax room type, 2 + 2 dual frequency, smart antenna, Bluetooth)
Huawei AirEngine 5762S-12SW is an indoor wireless access point (AP) in compliance of the Wi-Fi 6 (802.11ax) standard. It supports high bandwidth, high concurrency, and compact size, facilitating flexible deployment and saving customer investment. It is applicable to indoor coverage scenarios such as SMB office, houses, and hotels.
Table 1 shows the quick spec.
| Model | AirEngine 5762S-12SW |
CPU | 2-core, 1.0 GHz |
Memory | DDR3L: 512 MB |
Storage | NAND Flash 256 MB |
Console port | BLE console |
Maximum power consumption [W] | 12 W |
Maximum heat dissipation [BTU/hour] | 41 BTU/hour |
Power supply mode | PoE |
Input voltage range [V] | PoE: 802.3af |
Maximum number of physical ports on the entire device | GE (RJ45) x 2, 10M/100M/1000M auto-sensing |
Long-term operating temperature [°C(°F)] | 0°C to 40°C (If the altitude is higher than 1800 m, the temperature decreases by 1°C every time the altitude increases by 300 m.) |
Storage temperature [°C(°F)] | -40°C to 70°C |
Long-term operating relative humidity [RH] | 5% RH to 95% RH |
Long-term operating altitude [m(ft.)] | -60m to 5000m |
Atmospheric pressure [kPa] | 53Kpa ~ 106Kpa ETSI 300 019-2-3 |
Ground | floating ground |
BLE | BLE5.0 |
Radio number | 12:00 AM |
MTBF [year] | 69.7 year |
MTTR [hour] | 0.5 hour |
802.3af power supply description | No function is limited. |
