The Ruckus ICX 7150-24-4X1G is a high-performance, enterprise-class Layer 2/Layer 3 managed Ethernet switch designed to deliver reliable, scalable, and cost-effective network connectivity for small to medium-sized businesses, branch offices, educational institutions, hospitality environments, and enterprise edge deployments. Equipped with 24 Gigabit Ethernet RJ45 ports and 4 dedicated 1G SFP uplink ports, the ICX 7150-24-4X1G provides flexible connectivity options, enabling seamless integration with existing network infrastructure while supporting high-speed uplink connections for increased bandwidth and network efficiency. Powered by the advanced Ruckus ICX operating system, this switch offers comprehensive Layer 2 switching capabilities alongside Layer 3 static routing, IPv4/IPv6 support, VLAN segmentation, Quality of Service (QoS), Link Aggregation (LACP), Spanning Tree Protocol (STP/RSTP/MSTP), IGMP Snooping, Access Control Lists (ACLs), and enterprise-grade security features to ensure stable, secure, and optimized network performance. Designed for easy deployment and simplified management, the ICX 7150-24-4X1G supports both command-line interface (CLI) and web-based management, making configuration and ongoing maintenance straightforward for network administrators. The switch also features energy-efficient hardware, quiet operation, and a compact rack-mountable design, making it suitable for environments where reliability and low operating costs are essential. With its non-blocking architecture, wire-speed forwarding performance, and enterprise-level resiliency, the ICX 7150-24-4X1G can efficiently handle bandwidth-intensive applications such as VoIP, video conferencing, cloud services, wireless access, IP surveillance, and business-critical data traffic. Built with the proven quality and reliability of Ruckus networking solutions, this switch provides long-term investment protection through robust scalability, high availability, and seamless interoperability with Ruckus wireless access points and other enterprise networking equipment. The Ruckus ICX 7150-24-4X1G is an ideal networking solution for organizations seeking dependable Gigabit connectivity, simplified network management, enhanced security, and exceptional performance to support modern digital business operations.
ICX 7150-24-4X1G
Ruckus
Original New
1 year
| Quantity: | |
|---|---|
Item | Official Specification |
|---|---|
Model Number | ICX 7150-24-4X1G |
Brand & Series | RUCKUS ICX 7150 Stackable Enterprise Access Switch |
Typical Application | SMB Office Networks, Wireless AP Aggregation, IP Surveillance, Campus Edge, Small Business Backbone |
Warranty | RUCKUS Limited Hardware Warranty |
Port Configuration | 24 × 10/100/1000BASE-T RJ45 Non-PoE Downlinks 2 × Fixed 1G RJ45 Uplinks 4 × 1G SFP Slots (Upgradable to 10G SFP+ via license) |
PoE Support | No PoE / PoE+ |
Switching Capacity | 132 Gbps Full-Duplex |
64-byte Packet Forwarding Rate | 98 Mpps |
MAC Address Table | 16,000 MAC Entries |
Packet Buffer Memory | 2 MB Shared Buffer |
Jumbo Frame | Up to 9,000 Bytes |
Stacking Capability | Max 12 Switches per Stack, Max 480 Gbps Stack Bandwidth, Up to 10km Stack Distance |
Management Interfaces | Out-of-Band 1G RJ45 Management Port, RJ45 Console, USB-C Console, Web GUI, CLI, SNMP v1/v2/v3, RUCKUS Cloud |
VLAN Features | Up to 4,094 VLANs, 802.1Q Tagging, Voice VLAN, Private VLAN, Q-in-Q |
Spanning Tree Protocols | STP, RSTP, MSTP, PVST+, UDLD |
Link Aggregation | IEEE 802.3ad LACP, Static Trunks |
Multicast Functions | IGMP Snooping v1/v2/v3, MLD Snooping, PIM Snooping |
QoS | 8 Hardware Queues Per Port, WRR, Strict Priority, Port Rate Limiting, Storm Control |
Layer 3 Routing | Base: IPv4/IPv6 Static Routes, RIP v1/v2, RIPng Advanced L3 (License Required): OSPF, VRRP, PIM, PBR, ECMP |
Security Features | 802.1X Port Authentication, Web Auth, RADIUS/TACACS+, Port Security, ACL, SSH/HTTPS, DoS Protection, ARP Guard |
Monitoring Tools | sFlow, Port Mirroring, Cable Diagnostics, Event Logging |
Cooling System | Variable-Speed Front-to-Back Fans |
Physical Dimension (W × D × H) | 440 mm × 350 mm × 44 mm (17.32 × 13.78 × 1.73 in), 1U Rackmount |
Net Weight | 4.7 kg (10.36 lbs) |
Power Supply | Built-in Single AC Power, 100–240V AC 50/60Hz; No Redundant PSU Support |
Typical Idle Power Draw | 26 W |
Max Operating Power Draw | 38 W |
Operating Environment | Temperature: 0°C ~ 45°C Humidity: 10%–90% Non-Condensing |
Storage Environment | Temperature: -20°C ~ 70°C Humidity: 10%–90% Non-Condensing |
MTBF (25°C Ambient) | 1,450,000 Hours |
Installation Options | Standard 19-inch Rack Mount, Desktop Placement |
Regulatory Certifications | CE, FCC, UL, RoHS Compliant |
