MikroTik CRS317-1G-16S+RM 16-Port 10GbE SFP+ Managed Switch – L3, 1U Rackmount with Dual Redundant Power Supplies, 800MHz CPU, 1GB RAM

Share to:

MikroTik CRS317-1G-16S+RM 16-Port 10GbE SFP+ Managed Switch – L3, 1U Rackmount with Dual Redundant Power Supplies, 800MHz CPU, 1GB RAM

The MikroTik CRS317-1G-16S+RM is a high-performance 10 Gigabit managed switch designed for enterprise networks, data centers, ISPs, and demanding infrastructure environments that require fast, reliable, and flexible connectivity. It features 16 SFP+ ports, providing high-speed 10Gbps fiber connectivity for servers, storage systems, network aggregation, and other bandwidth-intensive devices, along with 1 Gigabit Ethernet port for management and network access. Powered by a powerful 800 MHz CPU and equipped with 1 GB of RAM, the CRS317-1G-16S+RM delivers efficient switching performance and supports advanced network management through MikroTik RouterOS and SwitchOS, allowing users to select the operating environment that best fits their requirements. The switch supports Layer 2 switching features and advanced management capabilities, making it suitable for building high-speed backbone, aggregation, and server networks. Its rack-mount design allows convenient installation in standard 19-inch network cabinets, while the compact 1U form factor helps optimize rack space. With its combination of 10G SFP+ connectivity, flexible management options, reliable hardware, and cost-effective design, the MikroTik CRS317-1G-16S+RM is an excellent choice for businesses, network integrators, data centers, and service providers looking to upgrade their infrastructure to high-speed 10 Gigabit networking while maintaining flexible deployment and long-term scalability.

Model:
CRS317-1G-16S+RM
Brand:
Mikrotik
Condition:
Original New
Warranty:
1 year

Availability:

Quantity:



Inquire Add to Basket

Category	Parameter	Specification
Basic Product Information	Model Name	CRS317-1G-16S+RM
	Product Series	MikroTik Cloud Router Switch (CRS) Series
	Device Type	Layer 3 Managed 10GbE SFP+ Switch
	Form Factor	1U Rack-mountable Chassis
	Target Application	Enterprise Networking, Data Center, Server Rack Connectivity, High-Speed Network Backbone
Hardware Specifications	CPU Model	Dual Core 800MHz ARM 32-bit (98DX8216)
	Switch Chip Model	Marvell Prestera 98DX8216
	RAM	1 GB
	Storage	16 MB Flash Memory
	MTBF	Approximately 200,000 hours at 25°C
Port Configuration	10/100/1000BASE-T RJ45 Ethernet Port	1 port (for management)
	10GbE SFP+ Slots	16 x SFP+ cages (support 10G/5G/2.5G/1G SFP/SFP+ transceivers)
	Serial Console Port	1 x RJ45 Serial Console Port
Performance Parameters	Switching Capacity	322 Gbps
	Forwarding Rate (64-byte packets)	239.6 Mpps
	MAC Address Table Size	16,000 entries
	Jumbo Frame Support	Up to 10,000 bytes
	Switching Architecture	Wire-speed, Non-blocking forwarding
Software & Management	Operating System	Dual Boot: RouterOS (License Level 6) / SwitchOS
	Management Methods	Winbox, Web-based GUI, CLI (SSH/Telnet/Serial Console), SNMP v2/v3
	Core Network Features	Layer 3 routing, 802.1Q VLAN, RSTP/MSTP, LACP Link Aggregation, IGMP Snooping, ACL Access Control List, Port Mirroring, Broadcast Storm Control
	Supported Protocols	IPv4/IPv6, OSPF, BGP, RIP, DHCP Server/Client, NAT
Power Supply & Cooling	Power Supply	Dual Redundant AC Power Supplies
	AC Input Range	100–240V AC, 50/60Hz
	Max Power Consumption	44 W
	Cooling Type	Passive cooling with 2 automatic fans (triggered at high temperatures)
	Fanless Operation	Yes (under normal temperature conditions)
Physical & Mechanical Specifications	Dimensions (W × D × H)	443 mm × 224 mm × 44 mm (1U rack height)
	Mounting	Standard 19-inch rack mount brackets included
	Indicators	38 LED indicators for port status, power, and system health
	Additional Features	CPU temperature monitor, built-in beeper
Environmental Operating Conditions	Operating Temperature	-20°C to +60°C (-4°F to 140°F)
	Storage Temperature	-40°C to +70°C (-40°F to 158°F)
	Operating Humidity	10%–90% non-condensing
Compliance & Certifications	Industry Standards	IEEE 802.3, 802.3u, 802.3ab, 802.3ae (10GbE), 802.1Q VLAN, 802.1p QoS, 802.1X Authentication, 802.3ad LACP
	Certifications	CE, EAC, RoHS
