The MikroTik CRS326-24G-2S+IN is a high-performance 24-port Gigabit Ethernet switch designed for enterprise networks, small and medium-sized businesses, server rooms, offices, and other demanding networking environments. It features 24 Gigabit Ethernet ports for reliable high-speed connectivity and 2 SFP+ ports supporting 10Gbps uplinks, making it an excellent choice for connecting access devices while providing fast connections to servers, storage systems, aggregation switches, or other network infrastructure. Powered by a modern switching architecture, the CRS326-24G-2S+IN provides efficient Layer 2 switching and advanced Layer 3 management capabilities, giving network administrators greater flexibility when building and managing professional networks. The switch runs MikroTik RouterOS, offering a wide range of configuration and management functions, including VLAN, VLAN filtering, link aggregation, port isolation, traffic management, access control, and various monitoring and diagnostic tools. Its 10G SFP+ interfaces are particularly useful for high-bandwidth backbone connections, helping reduce network bottlenecks in data-intensive applications and allowing the switch to integrate smoothly into existing 10Gbps network infrastructures. With a compact rack-mountable design and efficient hardware architecture, the MikroTik CRS326-24G-2S+IN is suitable for centralized network deployment where reliable Gigabit access and high-speed uplinks are required. It can be used in enterprise offices, education networks, retail environments, hospitality, surveillance systems, branch networks, and SMB infrastructure, providing a cost-effective solution for organizations that need dependable switching performance without unnecessary complexity. For system integrators, IT resellers, distributors, and professional network users, the CRS326-24G-2S+IN combines 24 Gigabit ports, 10G SFP+ uplinks, flexible RouterOS management, and MikroTik's powerful networking ecosystem in a practical and scalable switching platform.
CRS326-24G-2S+IN
Mikrotik
Original New
1 year
| Quantity: | |
|---|---|
Category | Parameter | Specification |
|---|---|---|
Basic Information | Model Name | CRS326-24G-2S+IN |
Product Series | MikroTik Cloud Router Switch (CRS) 300 Series | |
Device Type | Layer 3 Managed Switch / Router (Dual OS Support) | |
Form Factor | Desktop (Fanless Silent Design) | |
Target Application | SOHO, Small Office, Home Networking, IP Camera Systems, Wireless AP Backhaul | |
Hardware Specifications | CPU Model | 98DX3236 |
CPU Architecture | ARM 32-bit | |
CPU Core Count | 2 | |
CPU Frequency | 800 MHz | |
Switch Chip Model | 98DX3236 | |
RAM | 512 MB | |
Storage | 16 MB Flash Memory | |
RouterOS License Level | Level 5 | |
Port Configuration | 10/100/1000BASE-T RJ45 Ports | 24 x Non-PoE Gigabit Ethernet Ports |
10G SFP+ Uplink Slots | 2 x SFP+ Slots (Support 1G/10G SFP/SFP+ Transceivers) | |
Power Input Interfaces | 1 x DC Jack, 1 x Passive PoE-IN Port | |
Console Port | 1 x RJ45 Serial Console Port | |
Performance Specifications | Switching Capacity | 52 Gbps (Non-blocking, Wire-speed) |
Forwarding Rate | 38.69 Mpps (for 64-byte Packets) | |
MAC Address Table Size | 16,000 Entries | |
VLAN Support | Up to 4,094 VLANs (IEEE 802.1Q Tagged) | |
Jumbo Frame Support | Up to 10,218 Bytes | |
Link Aggregation | Up to 16 LACP Groups, 8 Ports per Group (802.3ad Compliant) | |
Power Supply | Input Voltage | 10 - 30 V DC (DC Jack / Passive PoE-IN) |
Max Power Consumption | 21 W | |
Included Accessory | 24 V 1.2 A DC Power Adapter | |
Cooling Type | Passive Cooling (Fanless, No Noise) | |
Physical & Environmental | Dimensions (W × D × H) | 285 mm × 144 mm × 44 mm |
Operating Temperature | -40°C to +60°C (Tested) | |
Storage Temperature | -40°C to +70°C | |
Operating Humidity | 10% - 90% Non-condensing | |
MTBF | Approx. 200,000 Hours at 25°C | |
Software & Core Features | Operating System | Dual Boot: RouterOS / SwOS (SwitchOS) |
Layer 3 Functions (RouterOS) | Static Routing, Inter-VLAN Routing, NAT, Firewall, VPN Support, DHCP Server/Client | |
Layer 2 Functions | 802.1Q VLAN, RSTP Spanning Tree, IGMP Snooping, Port Mirroring, Port Isolation, Broadcast Storm Control | |
QoS Features | 802.1p CoS, DSCP Mapping, Traffic Shaping & Policing | |
Management & Security | Management Methods | Web-based GUI, Winbox, CLI via Serial Console, SNMP v1/v2c/v3 |
Security Features | Access Control List (ACL), MAC Filtering, Port Security, DoS Protection, Encrypted Passwords, Secure SSH/HTTPS Management | |
Network Discovery | MikroTik Neighbor Discovery Protocol (MNDP) | |
Compliance & Certifications | Industry Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1X, IEEE 802.3ad LACP, RSTP |
Certifications | CE, FCC, RoHS, UL Safety Certification |
