MikroTik CRS418-8P-8G-2S+5axQ2axQ-RM All-in-One PoE Switch, Router & Wi-Fi 6 Access Point – 16 GbE Ports, 2x 10G SFP+, 150W PoE

Share to:

MikroTik CRS418-8P-8G-2S+5axQ2axQ-RM All-in-One PoE Switch, Router & Wi-Fi 6 Access Point – 16 GbE Ports, 2x 10G SFP+, 150W PoE

The MikroTik CRS418-8P-8G-2S+5axQ2axQ-RM is a powerful all-in-one managed network switch designed for modern enterprise, ISP, hospitality, and advanced home networking environments that require high-speed connectivity, PoE capability, and integrated wireless performance. Combining an 8-port Gigabit Ethernet switch with PoE-out support, 8 additional Gigabit Ethernet ports, 2 × 10G SFP+ uplink ports, and built-in Wi-Fi 6 wireless technology, this device provides a flexible and efficient solution for deploying high-performance wired and wireless networks. Powered by the advanced MikroTik RouterOS and SwOS, the CRS418-8P-8G-2S+5axQ2axQ-RM offers comprehensive Layer 2 management features, including VLAN configuration, link aggregation, traffic monitoring, port isolation, and advanced network control functions, making it suitable for professional network administrators and system integrators. The 8 PoE-out ports simplify the installation of compatible devices such as IP cameras, wireless access points, IP phones, and other PoE-enabled equipment by reducing the need for separate power supplies and additional cabling. With 2 × 10G SFP+ ports, the switch delivers high-speed uplink connectivity for data centers, backbone networks, and bandwidth-intensive applications, ensuring fast and reliable data transmission. Equipped with dual-band Wi-Fi 6 technology, including 2.4 GHz and 5 GHz wireless connectivity, the CRS418-8P-8G-2S+5axQ2axQ-RM provides enhanced wireless coverage, higher capacity, lower latency, and improved performance for multiple connected devices. Its rack-mountable design makes it ideal for professional deployments where space efficiency and centralized network management are important. Whether used in business offices, hotels, surveillance systems, educational institutions, or ISP networks, the MikroTik CRS418-8P-8G-2S+5axQ2axQ-RM delivers reliable switching, powerful PoE functionality, high-speed uplinks, and next-generation wireless networking in a single compact device, helping businesses build scalable, secure, and high-performance network infrastructures.

Model:
CRS418-8P-8G-2S+5axQ2axQ-RM
Brand:
Mikrotik
Condition:
Original New
Warranty:
1 year

Availability:

Quantity:



Inquire Add to Basket

Category	Parameter	Specification
Basic Information	Model Name	CRS418-8P-8G-2S+5axQ2axQ-RM
	Product Series	MikroTik CRS418 Series
	Device Type	Cloud Router Switch with Integrated Wi-Fi 6 AP
	Form Factor	1U Rack-mountable Chassis
	Typical Application	Medium-sized Offices, Labs, Server Rooms, Hybrid Network Deployments
Core Hardware Specifications	CPU	Quad-Core IPQ-8072A, 2208 MHz (ARM 64-bit Architecture)
	RAM	1 GB DDR3L
	Storage	128 MB NAND Flash
	Switch Chip Model	98DX226S
Port Configuration	10/100/1000BASE-T RJ45 Ports	17 x Gigabit Ethernet Ports (8 x PoE-out ports: Ether9-Ether16)
	10G SFP+ Uplink Slots	2 x 10 Gigabit SFP+ Slots (support 10G fiber/copper transceivers)
	USB Port	1 x USB 3.0 Type-A Port
	Management Console Port	1 x RJ45 Console Port (115200bps, 8N1)
PoE-Out Specifications	PoE Standard	IEEE 802.3af / 802.3at Compliant
	Total PoE Output Power	150 W
	Per-port Current Limit (Low Voltage <30V)	1.1 A
	Per-port Current Limit (High Voltage >30V)	0.56 A
	PoE Management	Per-port power monitoring, priority power allocation, PoE scheduling
Wireless Specifications (Wi-Fi 6)	2.4 GHz Band	802.11b/g/n/ax (Wi-Fi 6), QCN-5024 Chipset, 4x4 MIMO, Max 1148 Mbit/s Data Rate, 5 dBi Antenna Gain
	5 GHz Band	802.11a/n/ac/ax (Wi-Fi 6), QCN-5054 Chipset, 4x4 MIMO, Max 2400 Mbit/s Data Rate, 6 dBi Antenna Gain
	MIMO Support	DL 4x4 MIMO, UL 1x1 MIMO (5G SA UL 2x2 MIMO)
Switch & Performance Features	Switching Capacity	128 Gbps
	Forwarding Rate	95 Mpps (64-byte packets)
	MAC Address Table Size	32,768 Entries
	VLAN Support	Up to 4,094 802.1Q Tagged VLANs, Voice VLAN, Guest VLAN
	Layer 2 Features	STP/RSTP/MSTP, Link Aggregation (LACP 802.3ad), IGMP Snooping v1/v2/v3, Port Security, Storm Control, Port Mirroring (SPAN)
	Layer 3 Features	Static IPv4/IPv6 Routing, Inter-VLAN Routing, DHCP Server/Snooping, IPv4/IPv6 ACLs, OSPF, BGP
Power Supply Specifications	AC Input	2 x AC Inputs, 100-240V AC, 50/60Hz
	PSU Slots	2 x Hot-swappable PSU Slots
	Max Power Consumption (with attachments)	227 W
	Max Power Consumption (without attachments)	43 W
Mechanical & Physical Specs	Dimensions (W × D × H)	443 mm × 250 mm × 44 mm (without antennas); 443 mm × 250 mm × 210 mm (with antennas)
	Cooling System	4 x Fans (fan speed controlled)
	Mounting	Standard 19-inch 1U Rack Mount
Environmental & Reliability	Operating Temperature	-20°C to +70°C (-4°F to 158°F)
	Storage Temperature	-40°C to +70°C (-40°F to 158°F)
	Operating Humidity	10%–90% Non-condensing
	MTBF	Approximately 200,000 hours at 25°C
	Certifications	CE, FCC, RoHS, UL Safety Certified
Operating System & Management	Operating System	RouterOS v7
	License Level	License Level 5
	Management Methods	WebFig (Web UI), CLI, SNMP v1/v2c/v3, SSH, Telnet, MikroTik Cloud Management
	Firmware & Config	TFTP/FTP Firmware Upgrade, Configuration Backup/Restore
