MikroTik RB960PGS-PB is a compact and powerful Gigabit Ethernet switch designed for small and medium-sized network deployments that require reliable performance, flexible connectivity, and efficient power management. Featuring five Gigabit Ethernet ports and one Gigabit SFP port, the RB960PGS-PB provides high-speed wired connections and fiber uplink capability, making it an ideal choice for SOHO networks, small businesses, surveillance systems, wireless installations, and professional networking environments. This model supports PoE output on Ethernet ports, allowing users to power compatible devices such as wireless access points, IP cameras, and other network equipment directly through the network cable, reducing installation complexity and the need for additional power adapters. Powered by the advanced RouterOS operating system, the RB960PGS-PB offers comprehensive Layer 3 routing features, firewall functions, bandwidth management, VPN support, VLAN configuration, and advanced network monitoring capabilities. Its durable desktop design with a compact form factor makes it easy to deploy in space-limited environments, while the reliable hardware architecture ensures stable operation for continuous network services. With excellent flexibility, cost-effective performance, and professional-grade networking features, the MikroTik RB960PGS-PB is a practical solution for businesses, system integrators, and network professionals looking for an affordable Gigabit PoE switch with advanced routing capabilities. As an original MikroTik network equipment supplier, we provide brand-new RB960PGS-PB units with competitive pricing, stable supply, and professional support for global customers.
RB960PGS-PB
Mikrotik
Original New
1 year
| Quantity: | |
|---|---|
Category | Parameter | Specification |
|---|---|---|
Basic Information | Product Model | RB960PGS-PB (PowerBox Pro) |
Product Type | Outdoor/Indoor Gigabit Ethernet PoE Router | |
Architecture | MIPSBE | |
Operating System | MikroTik RouterOS | |
RouterOS License Level | 4 | |
Hardware Core Specifications | CPU Model | Qualcomm Atheros QCA9557 |
CPU Frequency | 800 MHz (1 core) | |
Switch Chip Model | Qualcomm Atheros QCA8337 | |
RAM Size | 128 MB | |
Flash Storage | 16 MB | |
Memory Type | FLASH | |
Port & Interface Configuration | 10/100/1000BASE-T Ethernet Ports | 5 x RJ45 Gigabit Ethernet ports (Auto MDI/X supported) |
SFP Fiber Port | 1 x Gigabit SFP slot (for fiber connectivity) | |
Power Input Interfaces | 2 x DC inputs (DC jack + PoE-IN) | |
DC Jack Spec | 5.5mm outer / 2mm inner female connector | |
Power & PoE Specifications | DC Input Voltage | 12-57 V |
PoE-In Standard | Passive PoE | |
PoE-Out Ports | Ether2 - Ether5 (4 ports) | |
PoE-Out Standard | IEEE 802.3af / 802.3at compliant | |
PoE-Out Current Limit | 1A max per port; 2A max total (12-30V input); 450mA max per port (31-57V input) | |
Max Power Consumption | 54 W (with attachments); 6 W (base unit only) | |
Cooling Type | Passive cooling (fanless) | |
Performance Specifications | Switching Capacity | 2 Gbps |
Forwarding Rate (64-byte packets) | 2.7 Mpps | |
Bridging Throughput (Fast Path) | Up to 1966 Mbps | |
Routing Throughput (Fast Path) | Up to 1966 Mbps | |
MTBF | Approximately 200,000 hours at 25°C | |
Physical & Environmental Specifications | Dimensions (W × D × H) | 125 mm × 225 mm × 52 mm |
Operating Temperature | -40°C to +70°C (tested) | |
Storage Temperature | -40°C to +70°C | |
Operating Humidity | 10% - 90% non-condensing | |
Protection Design | Outdoor-rated, IP54 (splash and dust resistant) | |
Management & Features | Management Methods | Winbox, WebFig, CLI, SNMP |
Supported Features | VLAN, RSTP, LACP, BGP, OSPF, MPLS, NAT, Firewall, QoS, DHCP Server/Client, PoE scheduling, Voltage/PCB temperature monitoring | |
Compliance & Certifications | Regulatory Standards | CE, FCC, IC, RoHS |
Networking Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at |
