CRS310-1G-5S-4S+OUT
Mikrotik
Original New
1 year
| Quantity: | |
|---|---|
Category | Parameter | Specification |
|---|---|---|
Basic Information | Product Model | CRS310-1G-5S-4S+OUT |
Product Series | MikroTik netFiber 9 / Cloud Router Switch (CRS) Series | |
Device Type | Outdoor Layer 2/Layer 3 Managed Fiber Switch | |
Core Application | ISP Outdoor Deployments, FTTH/FTTB Networks, High-Speed Fiber Backhaul, Long-Distance Network Connections | |
Port Configuration | 10/100/1000BASE-T RJ45 Port | 1 x Gigabit Ethernet port (supports 802.3af/at & passive PoE-in, direct connection to switch chip) |
1G SFP Slots | 5 x SFP slots (compatible with 1G fiber/copper SFP transceivers) | |
10G SFP+ Slots | 4 x SFP+ slots (compatible with 10G fiber/copper SFP+ transceivers) | |
Management Interfaces | 1 x RJ45 Serial Console Port | |
Performance Specifications | Switching Capacity | 90.8 Gbps (Non-blocking Layer 2 full capacity) |
Forwarding Rate (64-byte packets) | 68.45 Mpps | |
MAC Address Table Size | Up to 16,000 entries | |
VLAN Support | Up to 4,094 VLANs (802.1Q tagged, hardware offloaded VLAN filtering) | |
Jumbo Frame Support | Up to 10,218 bytes | |
Switch Chip Model | Marvell 98DX226S | |
Hardware Specifications | CPU | Marvell 98DX226S (ARM 32-bit architecture, 1 core, 800 MHz nominal frequency) |
RAM | 256 MB DDR3 | |
Storage | 16 MB Flash | |
Cooling Type | Passive cooling (fanless, silent operation) | |
MTBF | Approximately 200,000 hours at 25°C | |
Power Supply Specifications | Power Input Options | 2 x DC inputs (PoE-in + DC jack) |
PoE-in Standard | IEEE 802.3af/at, passive PoE | |
Input Voltage Range | 18-57 V DC | |
Max Power Consumption | 16.3 W (full load), 10 W (no attachments) | |
Software & Feature Support | Operating System | RouterOS v7 / SwitchOS |
RouterOS License Level | License 5 | |
Layer 2 Features | 802.1Q VLAN, Voice VLAN, STP/RSTP/MSTP loop prevention, LACP link aggregation, IGMP Snooping v1/v2/v3, Port Security, Storm Control, Port Mirroring (SPAN) | |
Layer 3 Features | Hardware offloaded static IPv4/IPv6 routing, Inter-VLAN routing, DHCP Server/Snooping, IPv4/IPv6 ACL access control lists | |
QoS Features | Hardware offloaded QoS, 802.1p CoS/DSCP mapping, traffic shaping & policing, priority traffic scheduling | |
Security Features | SSH/HTTPS secure management, SNMPv3, RADIUS/TACACS+ authentication, DoS attack protection, port isolation, configuration encryption | |
Management Methods | Web-based GUI, Command Line Interface (CLI), SNMP v1/v2c/v3, MikroTik Cloud Management | |
Environmental & Physical Specs | Operating Temperature | -40°C to +70°C (-40°F to 158°F) |
Storage Temperature | -40°C to +70°C (-40°F to 158°F) | |
Operating Humidity | 10%–90% non-condensing | |
IP Rating | IPX0 (outdoor-rated enclosure, no water contamination protection) | |
Dimensions (W × D × H) | 200 mm × 166 mm × 45 mm | |
Mounting | Wall/pole mountable (outdoor enclosure design) | |
Compliance & Certifications | Regulatory Certifications | CE, FCC Class A, RoHS, UL Safety Certification |
Supported Standards | IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3ae, 802.1Q, 802.1p, 802.1X, 802.3ad |
