CRS310-1G-5S-4S+IN
Mikrotik
Original New
1 year
| Quantity: | |
|---|---|
Category | Parameter | Specification |
|---|---|---|
Basic Information | Model Name | CRS310-1G-5S-4S+IN |
Product Series | MikroTik Cloud Router Switch (CRS) Series | |
Device Type | 10G SFP+ Fiber Managed Switch | |
Application Scenarios | Small Office, ISP, Enterprise Network, Long-distance Fiber Connection, High-bandwidth Data Transmission | |
Port Configuration | 10/100/1000BASE-T RJ45 Port | 1 x Gigabit Ethernet Port (direct connection to switch chip, wire-speed performance) |
1G SFP Ports | 5 x 1G SFP Slots (compatible with 1G fiber/copper SFP transceivers) | |
10G SFP+ Ports | 4 x 10G SFP+ Slots (compatible with 10G SFP+ transceivers, support 10G fiber links over 100 meters) | |
PoE Support | 802.3af/at PoE-In on the RJ45 management port | |
Performance Specifications | Switching Capacity (Non-blocking Layer 2) | 90.8 Gbps |
Forwarding Rate (64-byte packets) | 68.45 Mpps | |
Forwarding Rate (512-byte packets) | 10.81 Mpps | |
Forwarding Rate (1518-byte packets) | 3.74 Mpps | |
Switch Chip Model | Marvell 98DX226S (integrated CPU + switch ASIC) | |
Jumbo Frame Support | Yes | |
Hardware & System | CPU Model | Marvell 98DX226S |
CPU Architecture | ARM 32-bit | |
CPU Core Count | 2 Cores | |
CPU Frequency | 800 MHz | |
RAM | 256 MB DDR3 | |
Storage | 16 MB Flash Memory | |
Operating System | RouterOS v7 (License Level 5) / SwitchOS (dual boot option) | |
Management | CLI, WebFig, SNMP, SSH, Telnet | |
Power & Cooling | Power Input Options | 2 x DC Inputs (5.5mm DC Jack + 802.3af/at PoE-In) |
DC Input Voltage | 18-57 V DC | |
PoE-In Standard | IEEE 802.3af / 802.3at | |
Max Power Consumption | 20 W (full load) | |
Idle Power Consumption | 8 W (without attachments) | |
Cooling Type | 1 x Cooling Fan | |
Power Protection | Overvoltage, overcurrent, short circuit protection | |
Physical & Environmental | Dimensions (W × D × H) | 200 mm × 166 mm × 44 mm |
Mounting | 1U Rack-mountable (rack ears included) | |
Operating Temperature | -40°C to +70°C | |
Storage Temperature | -40°C to +70°C | |
Operating Humidity | 10%–90% non-condensing | |
MTBF | Approximately 200,000 hours at 25°C | |
IP Rating | IPX0 (indoor use only) | |
Compliance & Standards | Industry Standards | IEEE 802.3, 802.3u, 802.3ab, 802.3ae (10G Ethernet); IEEE 802.3af/at PoE; IEEE 802.1Q VLAN, 802.1p QoS |
Certifications | CE, FCC, RoHS, UL, EAC | |
Core Network Features | Layer 2 Functions | 802.1Q VLAN, Voice VLAN, STP/RSTP/MSTP, Link Aggregation (LACP), IGMP Snooping, Port Security, 802.1X Authentication, Storm Control, Port Mirroring |
Layer 3 Functions | Static IPv4/IPv6 Routing, Inter-VLAN Routing, DHCP Server/Client, ACL Access Control Lists | |
QoS | 802.1p CoS, DSCP mapping, traffic shaping, priority queuing | |
Security | Firewall, NAT, VPN support, DoS attack protection, encrypted management access |
