The MikroTik CCR2216-1G-12XS-2XQ is a high-performance enterprise and data center cloud core router engineered to deliver exceptional routing capacity, ultra-fast connectivity, and outstanding reliability for demanding network environments. Powered by a powerful 16-core 64-bit ARM processor and advanced networking architecture, this flagship router is designed to handle massive traffic loads, complex routing tasks, and bandwidth-intensive applications with remarkable efficiency. Featuring one Gigabit Ethernet management port, twelve 25G SFP28 ports, and two 100G QSFP28 ports, the CCR2216-1G-12XS-2XQ provides flexible high-density connectivity for modern enterprise networks, ISP backbone deployments, cloud infrastructure, data centers, carrier-grade services, and large campus networks. Its powerful hardware acceleration and optimized RouterOS operating system enable advanced Layer 3 routing, dynamic routing protocols including BGP, OSPF, and RIP, MPLS, VPN, VLAN, QoS, firewall, load balancing, traffic shaping, bandwidth management, and comprehensive security features, making it an ideal solution for mission-critical networking applications. Designed with high availability in mind, the router incorporates redundant hot-swappable power supplies, intelligent cooling, and a robust rack-mount chassis to ensure continuous operation and maximum uptime even in the most demanding environments. The combination of 25G and 100G interfaces allows organizations to build scalable and future-ready network infrastructures while reducing latency and increasing overall network efficiency. Whether deployed as a core router, aggregation router, edge router, or data center gateway, the CCR2216-1G-12XS-2XQ delivers enterprise-class performance, exceptional throughput, and reliable long-term operation. Its support for advanced management, monitoring, automation, and network optimization simplifies deployment and maintenance while providing administrators with complete control over network resources. Fully compatible with MikroTik RouterOS, the device offers unmatched flexibility for customized network configurations, making it suitable for telecommunications providers, cloud service providers, government organizations, educational institutions, financial enterprises, and large commercial businesses seeking secure, scalable, and cost-effective networking solutions. The MikroTik CCR2216-1G-12XS-2XQ combines cutting-edge hardware, industry-leading performance, and outstanding reliability into a single platform, making it one of the most powerful Cloud Core Routers available for organizations that require high-speed connectivity, maximum scalability, and uncompromising network performance.
CCR2216-1G-12XS-2XQ
Mikrotik
Original New
1 year
| Quantity: | |
|---|---|
Category | Parameter | Specification |
|---|---|---|
Basic Information | Model Name | CCR2216-1G-12XS-2XQ |
Product Series | MikroTik Cloud Core Router (CCR) Series | |
Device Type | Enterprise Grade 100G Layer 3 Hardware Offloading Router | |
Typical Application | Data Center Routing, ISP Backbone, Enterprise Core Network, High-Speed Network Aggregation | |
Core Hardware Specifications | CPU Model | AL73400 |
CPU Architecture | ARM 64-bit | |
CPU Core Count | 16 Cores | |
CPU Nominal Frequency | 2 GHz | |
RAM Size & Type | 16 GB DDR4 | |
Onboard Storage | 128 MB NAND Flash | |
Switch Chip Model | 98DX8525 | |
Switch-CPU Connection | 4 x 25 Gbps | |
Expansion Slots | 2 x M.2 SATA Slots (for additional storage) | |
Port Configuration | 1G Ethernet Port | 1 x 10/100/1000BASE-T RJ45 Port |
25G SFP28 Ports | 12 x SFP28 Slots (support 25G fiber/copper transceivers) | |
100G QSFP28 Ports | 2 x QSFP28 Slots (support 100G transceivers) | |
Management Console Port | 1 x RJ45 Serial Console Port | |
Performance Specifications | Switching Capacity | 1.2 Tbps (Non-blocking Wire-speed) |
Forwarding Rate | 960 Mpps (64-byte packets) | |
Hardware Offloading | Layer 3 Hardware Offloading, MPLS Hardware Offloading | |
VLAN Support | Up to 4,094 VLANs (802.1Q Tagged) | |
Jumbo Frame Support | Up to 9,216 Bytes | |
Layer 2 Features | IGMP/MLD Snooping, DHCP Snooping with Option 82, Port Isolation, Storm Control, Port Mirroring | |
Layer 3 Features | Static/Dynamic Routing, Inter-VLAN Routing, BGP, OSPF, RIP, MPLS, VRF | |
System & Software | Operating System | RouterOS v7 |
RouterOS License Level | License Level 6 | |
Management Methods | WebFig (Web UI), CLI, WinBox, SNMP v1/v2c/v3, SSH, Telnet | |
Security Features | Firewall, NAT, VPN (IPsec, L2TP, PPTP, SSTP), Access Control List, DoS Attack Protection | |
Power Supply | Power Input | 2 x Redundant Hot-swap AC Power Supplies |
AC Input Range | 100–240 V AC, 50/60 Hz | |
Nominal Voltage & Current | 12 V DC, 12.5 A | |
Max Power Consumption (without attachments) | 80 W | |
Max Total Power Consumption | 128 W | |
Physical & Environmental | Dimensions (W × D × H) | 443 mm × 367 mm × 44 mm (1U Rack Height) |
Cooling System | 4 x Hot-swap Fans, Fanless Option Available | |
Operating Temperature | -20°C to +60°C (-4°F to 140°F) | |
Storage Temperature | -40°C to +70°C (-40°F to 158°F) | |
Operating Humidity | 10%–90% Non-condensing | |
MTBF | Approximately 200,000 hours at 25°C | |
Included Accessories | Standard Package Contents | 2 x Power Cords, Rackmount Ears, Rear Cable Management Support Ears, Fastening Set Bracket |
