The MikroTik RB750r2 (hEX lite) is a compact, cost-effective Ethernet router designed for small businesses, branch offices, home offices, and network enthusiasts who require reliable wired routing performance with advanced network management capabilities. Equipped with a powerful 850MHz CPU, 64MB of RAM, and five 10/100 Fast Ethernet ports, the RB750r2 delivers stable data forwarding, firewall protection, NAT, VPN support, bandwidth management, and traffic shaping, making it an excellent choice for secure and efficient network deployment. Powered by MikroTik's industry-leading RouterOS, the RB750r2 offers a comprehensive range of enterprise-class networking features, including static and dynamic routing, VLAN support, DHCP server and client, PPPoE, hotspot gateway, IPsec, OpenVPN, L2TP, PPTP, queue management, firewall filtering, QoS, load balancing, and advanced monitoring tools, allowing network administrators to customize and optimize their networks with exceptional flexibility. Its fanless, compact desktop design ensures silent operation and long-term reliability while consuming minimal power, making it ideal for continuous 24/7 operation in offices, retail stores, educational institutions, hotels, and other small-scale networking environments. The RB750r2 is easy to deploy, highly stable, and fully compatible with existing Ethernet infrastructures, providing dependable wired connectivity for computers, printers, IP phones, surveillance systems, and other network devices. Whether used as a primary router, VPN gateway, firewall appliance, or branch office router, the MikroTik RB750r2 offers outstanding value by combining professional-grade RouterOS functionality with affordable pricing, making it one of the most popular entry-level routers for businesses, system integrators, IT service providers, and network professionals seeking a reliable, secure, and feature-rich networking solution.
RB750r2
Mikrotik
Original New
1 year
| Quantity: | |
|---|---|
Category | Parameter | Specification |
|---|---|---|
Basic Product Information | Model Name | RB750r2 (hEX lite) |
Brand | MikroTik | |
Product Type | Wired Ethernet Router / SOHO Network Router | |
Target Application | Home Office, SOHO, Small Business Network, Home Network Management | |
Hardware Core Specifications | CPU Model | QCA9531-BL3A-R |
CPU Architecture | MIPSBE | |
CPU Core Count | 1 Core | |
CPU Nominal Frequency | 850 MHz | |
RAM Size | 64 MB | |
Flash Storage Size | 16 MB | |
Switch Chip Model | QCA9531-BL3A-R | |
Interface & Connectivity | Ethernet Ports | 5 x 10/100BASE-TX Fast Ethernet RJ45 Ports |
Power Input Interfaces | 1 x DC Power Jack (5.5mm outer, 2mm inner, female, pin positive) + 1 x Passive PoE IN Port (Port 1) | |
Other Interfaces | 1 x Reset Button, 1 x LED Indicator for Power/Activity | |
Power Supply & PoE | Supported Input Voltage | 6V - 30V DC (both DC jack and PoE IN port) |
PoE Type | Passive Power over Ethernet (PoE-IN on Port 1) | |
Max Power Consumption | 2 W | |
Included Power Adapter | 12V 0.5A DC Power Adapter (original packaging) | |
System & Software | Operating System | MikroTik RouterOS (pre-installed) |
RouterOS License Level | Level 4 | |
Default Configuration | Default IP: 192.168.88.1; Default username: admin; No default password | |
Supported Features | MPLS, Static/Dynamic Routing, Firewall, NAT, DHCP Server/Client, VLAN, QoS, VPN (PPTP/L2TP/IPSec), Bandwidth Management | |
Physical & Mechanical Specifications | Dimensions (W × D × H) | 113 mm × 89 mm × 28 mm |
Weight (without packaging) | 129 g | |
Installation Method | Desktop placement, Wall-mountable (mounting points reserved, screws not included) | |
Ingress Protection | IPX0 (indoor use only) | |
Environmental Specifications | Operating Temperature Range | -20°C to +70°C (-4°F to +158°F) |
Storage Temperature Range | -40°C to +85°C (-40°F to +185°F) | |
Operating Humidity | 10% - 90% non-condensing | |
Operating Altitude | Up to 2,000 meters above sea level | |
Compliance & Certifications | Industry Standards | IEEE 802.3 (10BASE-T), IEEE 802.3u (100BASE-TX) |
Regulatory Certifications | CE, FCC Class B, RoHS, WEEE | |
Warranty | 12-month official manufacturer warranty |
