FG-301E
Fortinet
Original New
1 year
| Quantity: | |
|---|---|
FortiGate 301E
The FortiGate 300E series provides an application-centric, scalable and secure SD-WAN solution with next generation firewall (NGFW) capabilities for mid-sized to large enterprises deployed at the campus or enterprise branch level. Protects against cyber threats with system-on-a-chip acceleration and industry-leading secure SD-WAN in a simple, affordable, and easy to deploy solution. Fortinet's Security-Driven Networking approach provides tight integration of the network to the new generation of security.
FortiGate 301E
Product Specifications
| FortiGate 301E | |
| Hardware Specifications | |
| GE RJ45 Interfaces | 16 |
| GE SFP Slots | 16 |
| GE RJ45 Management Ports | 2 |
| USB Ports | 2 |
| RJ45 Console Port | 1 |
| Local Storage | NIL |
| Included Transceivers | 2x 240 GB SSD |
| System Performance - Enterprise Traffic Mix | |
| IPS Throughput 2 | 5 Gbps |
| NGFW Throughput 2, 4 | 3.5 Gbps |
| Threat Protection Throughput 2, 5 | 3 Gbps |
| System Performance | |
| Firewall Throughput (1518 / 512 / 64 byte UDP packets) | 32 / 32 / 20 Gbps |
| Firewall Latency (64 byte UDP packets) | 3 μs |
| Firewall Throughput (Packets Per Second) | 30 Mpps |
| Concurrent Sessions (TCP) | 4 Million |
| New Sessions/Second (TCP) | 300,000 |
| Firewall Policies | 10,000 |
| IPsec VPN Throughput (512 byte) 1 | 20 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels | 2,000 |
| Client-to-Gateway IPsec VPN Tunnels | 50,000 |
| SSL-VPN Throughput | 2.5 Gbps |
| Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) | 500 |
| SSL Inspection Throughput (IPS, avg. HTTPS) 3 | 3.9 Gbps |
| SSL Inspection CPS (IPS, avg. HTTPS) 3 | 2,500 |
| SSL Inspection Concurrent Session (IPS, avg. HTTPS) 3 | 340,000 |
| Application Control Throughput (HTTP 64K) 2 | 7 Gbps |
| CAPWAP Throughput (HTTP 64K) | 5 Gbps |
| Virtual Domains (Default / Maximum) | 10 / 10 |
| Maximum Number of Switches Supported | 48 |
| Maximum Number of FortiAPs (Total / Tunnel Mode) | 512 / 256 |
| Maximum Number of FortiTokens | 1,000 |
| Maximum Number of Registered FortiClients | 600 |
| High Availability Configurations | Active-Active, Active-Passive, Clustering |
| Dimensions | |
| Height x Width x Length (inches) | 1.75 x 17.0 x 15.0 |
| Height x Width x Length (mm) | 44.45 x 432 x 380 |
| Weight | 16.6 lbs (7.6 kg) |
| Form Factor | 1 RU |
| Power Consumption (Average / Maximum) | 95 W / 180 W |
| Power Source | 100-240V 60-50Hz |
| Current (Maximum) | 6A |
| Heat Dissipation | 614 BTU/h |
| Redundant Power Supplies (Hot Swappable) | optional |
| Operating Environment and Certifications | |
| Operating Temperature | 32-104°F (0-40°C) |
| Storage Temperature | -31-158°F (-35-70°C) |
| Humidity | 10-90% non-condensing |
| Noise Level | 48 dBA |
| Operating Altitude | Up to 7,400 ft (2,250 m) |
| Compliance | FCC Part 15 Class A, C-Tick, VCCI, CE, UL/cUL, CB |
| Certifications | ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; USGv6/IPv6 |
