The MikroTik RB960PGS (hEX PoE) is a compact and powerful Gigabit Ethernet router designed for small to medium-sized business networks, home offices, and professional networking applications that require reliable performance, flexible management, and PoE capability. Powered by a high-performance CPU and equipped with five Gigabit Ethernet ports plus one SFP port, the RB960PGS provides fast wired connectivity and supports fiber uplink expansion for enhanced network scalability. With its built-in PoE output functionality, this router can power compatible network devices such as wireless access points, IP cameras, and other PoE-enabled equipment, reducing the need for additional power adapters and simplifying network deployment. Running on MikroTik’s advanced RouterOS operating system, the RB960PGS offers a wide range of professional networking features, including firewall, VPN, bandwidth management, VLAN, routing protocols, hotspot gateway, and advanced traffic control functions, making it suitable for both basic and complex network environments. Its compact fanless design ensures quiet operation, low power consumption, and easy installation in various locations. The MikroTik RB960PGS is an ideal choice for users looking for an affordable yet feature-rich Gigabit router with PoE support, excellent reliability, and enterprise-level network management capabilities. As an original MikroTik networking product, it delivers outstanding value for system integrators, IT professionals, resellers, and businesses seeking efficient and scalable network solutions.
RB960PGS
Mikrotik
Original New
1 year
| Quantity: | |
|---|---|
Category | Parameter | Specification |
|---|---|---|
Basic Product Information | Model Name | RB960PGS (hEX PoE) |
Brand | MikroTik | |
Product Type | Wired Gigabit Ethernet PoE Router | |
Target Application | Small business networks, home office, PoE device deployment (IP cameras, APs, VoIP phones), network routing & management | |
Core Hardware Specifications | CPU Model | QCA9557 |
CPU Core & Frequency | 1-core, 800 MHz nominal frequency | |
Architecture | MIPSBE | |
RAM Size | 128 MB | |
Flash Storage | 16 MB | |
Switch Chip | QCA8337 | |
RouterOS License | Level 4 (pre-installed, no additional purchase required) | |
Operating System | RouterOS (pre-installed, free lifetime software updates) | |
Port Configuration | Gigabit Ethernet Ports | 5 x 10/100/1000 Mbps RJ45 ports |
SFP Fiber Slot | 1 x Gigabit SFP slot (for fiber connectivity) | |
USB Port | 1 x USB 2.0 port | |
DC Input Interface | 1 x DC power jack | |
PoE-IN Port | 1 x passive PoE input port | |
PoE Power Specifications | PoE-Out Ports | 4 ports (Ether2 - Ether5) |
PoE Compliance | IEEE 802.3af / 802.3at standard compliant | |
Per-port Max Output | 1 A (low voltage) / 450 mA (high voltage) | |
Total Max PoE Output | 2 A | |
PoE Input Voltage | 12 - 57 V DC (passive PoE) | |
Performance Parameters | Fast Path Bridging Throughput | Up to 1966 Mbps (64-byte packets) |
Fast Path Routing Throughput | Up to 1966 Mbps (64-byte packets) | |
Concurrent Sessions | Up to 65,535 | |
NAT Throughput | Up to 1 Gbps | |
Power Supply Specifications | Max Power Consumption | 9 W (without attachments) / 54 W (full PoE load) |
DC Jack Input Voltage | 12 - 57 V DC | |
Included Power Adapter | 24V 2.5A DC power adapter | |
Mechanical & Environmental Specs | Dimensions (W × D × H) | 114 mm × 137 mm × 29 mm |
Cooling Type | Passive cooling (fanless, silent operation) | |
Operating Temperature | -40°C to 70°C | |
Storage Temperature | -40°C to 85°C | |
Operating Humidity | 10% - 90% non-condensing | |
Mounting Options | Desktop / DIN rail mount (DIN mount bracket included) | |
Management & Software Features | Management Interfaces | Web-based GUI (Winbox/Webfig), CLI, SNMP |
Supported Protocols | DHCP Client/Server, NAT, Firewall, 802.1Q VLAN, OSPF/RIP/BGP routing, PPP, IPsec/L2TP/PPTP VPN | |
Security Features | Built-in stateful firewall, DoS attack protection, encrypted management access, user authentication | |
Certifications & Compliance | Industry Certifications | CE, EAC, RoHS |
HS Code | 85176990 |
