The Ruckus ICX 7550-24ZP-E2 is a high-performance enterprise-class Layer 3 managed switch designed to deliver exceptional scalability, reliability, and advanced networking capabilities for modern campus, enterprise, education, healthcare, hospitality, and high-density business environments. Equipped with 24 multigigabit 1/2.5/5/10GbE PoE++ (802.3bt) ports, the switch provides high-speed connectivity and powerful power delivery for bandwidth-intensive devices such as Wi-Fi 6/6E/7 access points, IP surveillance cameras, VoIP phones, IoT devices, and edge computing equipment. Its robust PoE++ capability supports up to 90W per port, simplifying deployments by eliminating the need for separate power sources. The ICX 7550-24ZP-E2 features high-speed uplink options that enable seamless integration into enterprise core and aggregation networks while ensuring low-latency data transmission and high network availability. Built with advanced Layer 2 and Layer 3 switching, IPv4/IPv6 support, static routing, RIP, OSPF, VRRP, multicast routing, ACLs, QoS, network segmentation, and comprehensive security features, it delivers reliable performance for mission-critical business applications. The switch also supports advanced stacking technology for simplified management, increased resiliency, and future network expansion, allowing multiple switches to operate as a single logical unit. With enterprise-grade redundancy, energy-efficient operation, intelligent traffic management, and comprehensive network monitoring capabilities, the ICX 7550-24ZP-E2 helps organizations reduce operational complexity while maximizing network performance and uptime. Designed for organizations requiring scalable multigigabit infrastructure, it provides an ideal foundation for digital transformation initiatives, high-density wireless deployments, cloud applications, unified communications, and data-intensive workloads. Its intuitive management options, including command-line interface (CLI), web-based management, SNMP, automation support, and centralized network management compatibility, simplify deployment and ongoing maintenance. The Ruckus ICX 7550-24ZP-E2 is an excellent choice for businesses seeking a secure, high-capacity, future-ready switching solution that combines outstanding performance, flexible deployment, advanced security, and long-term investment protection for evolving enterprise network infrastructures.
ICX 7550-24ZP-E2
Ruckus
Original New
1 year
| Quantity: | |
|---|---|
Item | Official Specification |
|---|---|
Model Number | ICX7550-24ZP-E2 |
Product Series | RUCKUS ICX 7550 Mid-Range Stackable Multigigabit PoE Switch |
Primary Application | Enterprise Campus, Wi-Fi 6/7 AP Deployment, IP Camera, VoIP Phone, SMB Aggregation, IoT Network |
Warranty & Support | 3-year RUCKUS TAC Remote Support, Standard Hardware Warranty |
Downlink RJ45 Ports | 24 Multigigabit PoE++ ports: 12×10/100/1000/2.5G, 12×10/100/1000/2.5/5/10G |
Uplink/Stacking Ports | 2×40G/100G QSFP28 dual-mode ports, modular expansion slot |
PoE Standard | IEEE 802.3af, 802.3at PoE+, 802.3bt PoE++ (max 90W per port) |
Total PoE Power Budget | 2000W (with dual 1200W AC power supplies, 180–240V input) |
PoE Special Functions | Perpetual PoE, Fast-Boot PoE |
Switching Capacity | 1020 Gbps |
64-byte Packet Forwarding Rate | 761.9 Mpps |
MAC Address Table | 64,000 entries |
Packet Buffer Memory | 4 GB dynamic shared buffer |
Flash Storage | 4 GB |
Jumbo Frame Support | Up to 12288 bytes |
Stacking Capacity | Max 12 units per logical stack, aggregate stack bandwidth up to 2400 Gbps |
Hardware Queues | 8 egress queues per port, WRR + strict priority scheduling |
VLAN Support | Up to 4094 VLANs, 802.1Q tagging, Voice VLAN, Guest VLAN |
Spanning Tree Protocols | STP, RSTP, MSTP, PVST |
Link Aggregation | IEEE 802.3ad LACP, static LAGs |
Multicast Features | IGMP Snooping v1/v2/v3, MVR, PIM-SM/SSM |
Layer 3 Routing | Static IPv4/IPv6, RIP, OSPF, BGP, VRF, VXLAN |
Security Functions | 802.1X port auth, MACsec 256-bit encryption, RADIUS/TACACS+, DoS protection, port security, ARP guard, SSH/HTTPS management |
Management Interfaces | RJ45 Console, USB-C, 1G out-of-band management port, RUCKUS SmartZone, RUCKUS Cloud, Unleashed, CLI, Web UI, sFlow |
Cooling System | 3 hot-swappable variable-speed fans, front-to-back airflow |
Power Configuration | Dual hot-swappable redundant 1200W AC power supplies (load-sharing) |
Physical Dimension (W × D × H) | 440 mm × 406 mm × 44 mm (17.3 × 16 × 1.73 in), 1U standard rackmount |
Net Weight | 7.1 kg (15.65 lbs) |
Input Power | 100–240V AC, 50/60Hz, C14 power inlet |
Idle Power Consumption (No PoE) | 83.1 W |
Full Load Max Power (Full PoE Output) | 1183.7 W |
Operating Environment | Temperature: 0°C ~ 45°C; Humidity: 10%–90% non-condensing |
Storage Environment | Temperature: -20°C ~ 70°C; Humidity: 5%–95% non-condensing |
MTBF (25°C Ambient) | 1,450,000 hours |
Installation | Standard 19-inch rack mount, desktop placement |
Regulatory Certifications | FCC Class A, CE, UL, CSA, VCCI, RoHS Compliant, TAA Compliant |
