The Ruckus ICX 7150-48ZP-E2X10G is a high-performance, enterprise-class Layer 3 managed switch designed to deliver reliable, secure, and scalable network connectivity for modern business environments. Equipped with 48 Gigabit Ethernet PoE+ ports and 2 dedicated 10GbE SFP+ uplink ports, this switch provides outstanding bandwidth, flexible network expansion, and simplified deployment for organizations requiring high-density wired access and advanced network management. Supporting a generous PoE power budget, the ICX 7150-48ZP-E2X10G efficiently powers IP phones, wireless access points, surveillance cameras, IoT devices, and other PoE-enabled equipment without the need for additional power infrastructure, making it an ideal solution for enterprise campuses, branch offices, educational institutions, healthcare facilities, retail stores, hospitality environments, and government networks. Built with advanced Layer 2 and Layer 3 switching capabilities, including static routing, RIP, OSPF, VRRP, VLANs, QoS, ACLs, IPv4/IPv6 support, multicast management, link aggregation, and comprehensive security features, the switch ensures high-speed data transmission, optimized traffic management, and reliable network performance even in demanding applications. The integrated 10GbE uplinks eliminate network bottlenecks by providing fast connections to aggregation switches, servers, and storage systems, supporting growing business demands and bandwidth-intensive applications such as cloud services, unified communications, HD video conferencing, and virtualization. Ruckus SmartZone and ICX management features enable centralized configuration, monitoring, troubleshooting, and automation, significantly reducing operational complexity and maintenance costs while improving network visibility and efficiency. Designed for continuous operation, the ICX 7150-48ZP-E2X10G offers enterprise-grade reliability, energy-efficient operation, and robust hardware architecture to maximize uptime and minimize total cost of ownership. With its flexible deployment options, comprehensive security, advanced management capabilities, and future-ready scalability, the Ruckus ICX 7150-48ZP-E2X10G is an excellent choice for organizations seeking a dependable, high-capacity managed switch that supports evolving business applications and digital transformation initiatives while delivering exceptional performance, investment protection, and long-term network stability.
ICX 7150-48ZP-E2X10G
Ruckus
Original New
1 year
| Quantity: | |
|---|---|
Item | Official Specification |
|---|---|
Model SKU | ICX7150-48ZP-E2X10G |
Product Series | RUCKUS ICX 7150 Z-Series Multigigabit Stackable Access Switch |
Main Application | Enterprise Office, Hospitality, Retail, Education, High-Density Wi-Fi 6/6E AP Deployment, IP Camera & IP Phone Networks |
Warranty | RUCKUS Limited Lifetime Hardware Warranty |
Status | Discontinued since Jan 15, 2026 (Replacement models available upon request) |
Downlink Port Layout | 16 × 100/1000/2.5G Multigigabit RJ45 (PoH 802.3bt ready, up to 90W per port) 32 × 10/100/1000BASE-T RJ45 (802.3at PoE+) |
Uplink Ports (Base Configuration) | 6 × 1G SFP slots + 2 × 10G SFP+ slots; upgradable to max 8×10G SFP+ via license |
PoE Standards Supported | IEEE 802.3af (15.4W), IEEE 802.3at PoE+ (30W), PoH (Power over HDBaseT), 802.3bt ready |
PoE Power Budget (Single PSU) | 740W |
PoE Power Budget (Dual Redundant PSU) | 1480W |
Switching Bandwidth (Full Duplex) | 304 Gbps |
64-byte Packet Forwarding Rate | 226 Mpps |
MAC Address Table Capacity | 16,384 entries |
Packet Buffer Memory | 12 MB shared buffer |
Jumbo Frame Support | Up to 9216 bytes |
QoS Queues | 8 hardware queues per port, WRR + Strict Priority scheduling |
VLAN Support | 4094 VLANs, 802.1Q tagging, Voice VLAN, Guest VLAN, Private VLAN |
Spanning Tree Protocols | STP, RSTP, MSTP, PVST+, RPVST+ |
Link Aggregation | IEEE 802.3ad LACP, static trunk, up to 32 trunk groups |
Multicast Features | IGMP Snooping v1/v2/v3, MLD Snooping, Multicast VLAN Registration (MVR) |
Stacking Capability | Max 12 switches per stack, 480 Gbps aggregate stacking bandwidth |
Layer 3 Routing (Base License) | IPv4/IPv6 Static Routing, RIP |
Advanced Layer 3 (Optional License) | OSPF, VRRP, PIM, Policy-Based Routing (PBR) |
Security Functions | 802.1X Port Auth, Web Auth, RADIUS/TACACS+, Port Security, ARP Guard, DoS Protection, SSH/HTTPS encrypted management, Rogue DHCP suppression |
Management Interfaces | RJ45 Console, USB-C Console, Out-of-Band MGMT Ethernet, USB-A storage port, Web GUI, CLI, RUCKUS SmartZone |
Cooling System | Single hot-swappable fan tray, front-to-back airflow, fanless low-noise mode support |
Acoustic Noise Level | 52 dBA at 25°C ambient temperature |
Physical Dimension (W × D × H) | 440 mm × 332 mm × 44 mm (17.32 × 13.07 × 1.73 in), 1U standard rackmount |
Net Unit Weight | 6.61 kg (14.57 lbs) |
Power Supply (This SKU) | Single 920W hot-swappable AC power supply; dual PSU compatible |
Input Power Range | 100–240V AC, 50/60Hz universal input |
Idle Power Consumption (No PoE Load) | 50W @ 220V |
Max Full Load Power (740W PoE Output) | 932W total power draw |
Operating Environment | 0°C ~ 45°C operating temperature, 5%–95% non-condensing humidity |
Storage Environment | -25°C ~ 70°C storage temperature, 5%–95% non-condensing humidity |
MTBF (25°C Ambient) | 1,046,260 hours |
Installation Options | 19-inch standard rack mount, desktop placement |
Compliance Certifications | CE, FCC Class A, UL, CSA, RoHS Compliant |
