Ubiquiti USW-Pro-Max-24-PoE UniFi Switch Pro Max 24 PoE – 24-Port L3 Managed PoE++ Switch with 2.5GbE, 10G SFP+, 400W Budget, Etherlighting

Share to:

Ubiquiti USW-Pro-Max-24-PoE UniFi Switch Pro Max 24 PoE – 24-Port L3 Managed PoE++ Switch with 2.5GbE, 10G SFP+, 400W Budget, Etherlighting

The Ubiquiti USW-Pro-Max-24-PoE is a high-performance Layer 3 managed switch designed for enterprise networks, business environments, and professional UniFi deployments. It features 24 Ethernet ports with PoE support, including 8 2.5GbE PoE++ ports and 16 1GbE PoE+ ports, along with 2.5G and 10G SFP+ uplink connectivity for high-speed network expansion. With a total PoE power budget of up to 400W, the USW-Pro-Max-24-PoE can power compatible Wi-Fi access points, IP cameras, VoIP phones, and other network devices, helping simplify installation and reduce the need for separate power adapters. Its Etherlighting™ technology provides visual port identification for easier network management and troubleshooting, while advanced Layer 3 switching features support VLANs, inter-VLAN routing, link aggregation, and traffic management for flexible network configuration. Fully integrated with the UniFi Network application, this switch enables centralized monitoring, configuration, and management through an intuitive interface, making it an excellent choice for offices, schools, hotels, surveillance systems, and growing enterprise networks that require reliable connectivity, efficient PoE delivery, and scalable network performance.

Model:
USW-Pro-Max-24-PoE
Brand:
Ubiquiti
Condition:
Original New
Warranty:
1 year

Availability:

Quantity:



Inquire Add to Basket

Item	Specification
Model	USW‑Pro‑Max‑24‑PoE
Brand	Ubiquiti UniFi
Switch Layer	Layer 3
RJ45 Ports	16× GbE RJ45, 8× 2.5 GbE RJ45
SFP+ Ports	2× 10G SFP+ uplink ports
PoE Standard	PoE (802.3af), PoE+ (802.3at), PoE++ (802.3bt)
PoE Port Allocation	8× PoE/PoE+, 16× PoE++ (up to 60W per port)
Total PoE Budget	400WUbiquiti
Switching Capacity	112 GbpsUbiquiti
Non‑blocking Throughput	56 GbpsUbiquiti
Forwarding Rate	83.328 Mpps
Display	1.3‑inch touch LCM screenUniFi
Special Feature	Etherlighting™ port indicator
Power Input	100‑240V AC 50/60Hz, USP‑RPS DC backup input
Internal Power Module	450W AC/DC
Max Power Draw	50W (excluding PoE output)Ubiquiti
Enclosure Material	SGCC Steel
Mounting	19‑inch rack‑mountable
Supported Rack Depth	400‑1200 mm
Operating Temperature	-5 °C to 40 °C (23 °F‑104 °F)UniFi
Operating Humidity	10‑90% non‑condensing
Weight (without brackets)	5.1 kg (11.3 lb)
Weight (with brackets)	5.2 kg (11.5 lb)UniFi
Required Software	UniFi Network Controller 8.0.24 or newerUniFi
Certifications	CE, FCC, IC, NDAA CompliantUniFi
