Ubiquiti UniFi Building Bridge UBB-Single – 60 GHz Wireless Point-to-Point Bridge with 5 GHz Backup Radio, 1.7 Gbps Throughput, 500m Range, IPX6, PoE, Single Unit Replacement/Spare

Share to:

Ubiquiti UniFi Building Bridge UBB-Single – 60 GHz Wireless Point-to-Point Bridge with 5 GHz Backup Radio, 1.7 Gbps Throughput, 500m Range, IPX6, PoE, Single Unit Replacement/Spare

The Ubiquiti UBB-Single is a high-performance wireless bridge solution designed to provide fast, reliable point-to-point connectivity between buildings and network locations without the need for traditional wired connections. Operating on the 60 GHz radio band with advanced wireless technology, the UBB-Single is well suited for extending Ethernet networks across offices, warehouses, campuses, commercial buildings, and other locations where installing fiber or network cabling may be difficult or costly. Its dedicated wireless bridge architecture enables stable, low-latency data transmission and helps organizations establish efficient building-to-building network links while reducing installation complexity. The UBB-Single is designed for professional networking applications and can be deployed as part of a Ubiquiti wireless bridge solution to connect separate LAN environments over a dedicated wireless link. With its compact and purpose-built design, the unit can be installed in suitable indoor or outdoor networking environments and integrated into existing Ubiquiti network infrastructures. It is a practical choice for businesses, system integrators, IT professionals, and network installers looking for a reliable wireless alternative to physical Ethernet or fiber connections. Whether used for inter-building connectivity, network expansion, temporary infrastructure, or high-speed point-to-point links, the Ubiquiti UBB-Single provides a convenient and scalable approach to extending network connectivity while maintaining a professional deployment standard. ImportGM supplies Ubiquiti networking equipment for international customers and can support project requirements, bulk orders, channel purchases, and individual sourcing needs with professional export service.

Model:
UBB-Single
Brand:
Ubiquiti
Condition:
Original New
Warranty:
1 year

Availability:

Quantity:



Inquire Add to Basket

Item	Specification
Brand	Ubiquiti
Model	UBB-Single
Product Type	UniFi Building-to-Building Wireless Bridge
Radio Module	60 GHz Main Radio + 5 GHz Backup Radio
Max Throughput (60GHz)	Up to 1.7 Gbps
Max Throughput (5GHz Backup)	866.6 Mbps (80MHz BW)
Max Range	Up to 500 m (1640 ft, line-of-sight)
Antenna Gain	17.2 dBi (60GHz), 10 dBi (5GHz), 2 dBi (2.4GHz BLE)
Max TX Power (EIRP)	25 dBm (5GHz), 32~36.5 dBm (60GHz)
Network Interface	1 × 10/100/1000 Mbps Gigabit RJ45 Port
Management Interface	Bluetooth, Ethernet
GPS	Built-in GPS
Power Supply	48V Passive PoE / 802.3af supported, 48V 0.32A PoE adapter included
Max Power Consumption	11W
Enclosure	UV-resistant Polycarbonate, IPX6 Weatherproof
Dimensions	140 × 140 × 90 mm (5.51 × 5.51 × 3.54")
Weight	376 g (13.3 oz)
Mounting	Pole mount kit included; Wall mount sold separately
Wind Survivability	200 km/h (125 mph), Wind loading: 56 N
ESD/EMP Protection	±24kV Contact / Air discharge
Operating Temperature	-40°C ~ +70°C (-40°F ~ +158°F)
Operating Humidity	5% ~ 95%, non-condensing
Wireless Security	WPA2-AES
Supported Standards	802.11ad, 802.11ac, 802.11n/a/b/g
Management Software	UniFi Network Controller
Certifications	CE, FCC, IC, NDAA Compliant
