Ubiquiti UniFi Switch Flex Mini USW-Flex-Mini – Compact 5-Port Gigabit Layer 2 Managed Switch, PoE or USB-C Powered, 10 Gbps Switching Capacity

Share to:

Ubiquiti UniFi Switch Flex Mini USW-Flex-Mini – Compact 5-Port Gigabit Layer 2 Managed Switch, PoE or USB-C Powered, 10 Gbps Switching Capacity

The Ubiquiti USW-Flex-Mini is a compact and easy-to-deploy UniFi managed switch designed to provide reliable wired network connectivity for homes, small businesses, offices, retail environments, and other space-constrained installations. Featuring 5 Gigabit Ethernet ports, the USW-Flex-Mini provides flexible connectivity for computers, IP phones, access points, cameras, and other network devices while maintaining a small footprint that can be conveniently placed on a desk, shelf, or other limited-space location. As part of the UniFi ecosystem, the switch can be centrally managed through the UniFi Network platform, allowing network administrators to monitor connected devices, configure network settings, manage VLANs, and maintain network visibility from a unified interface. Its compact design makes it particularly suitable for expanding wired network connections without requiring a full-size rack-mounted switch, while its Gigabit Ethernet ports provide sufficient bandwidth for everyday business and network applications. The Ubiquiti USW-Flex-Mini is a practical choice for users looking for a compact, manageable, and cost-effective UniFi switch for reliable network expansion and centralized network management.

Model:
USW-Flex-Mini
Brand:
Ubiquiti
Condition:
Original New
Warranty:
1 year

Availability:

Quantity:



Inquire Add to Basket

Specification	Details
Product Name	UniFi Switch Flex Mini
Model	USW-Flex-Mini
Product Type	5-Port Gigabit Layer 2 Switch
Networking Interface	(5) 10/100/1000 Mbps RJ45 ports
PoE Input	1 port, 802.3af/at PoE (Pins 1, 2+; 3, 6-)
Switching Capacity	10 Gbps
Total Non-Blocking Throughput	5 Gbps
Forwarding Rate	7 Mpps
Supported VLANs	1,000
MAC Address Table Size	2,000 entries
Layer 2 Features	Port isolation, storm control, port mirroring, multicast & broadcast rate limiting, flow control, jumbo frames, egress rate limit
Power Method	(1) USB Type-C, 5V DC, 1A or (1) 802.3af/at PoE input
Power Supply	5V, 1A USB-C power adapter (included with single-unit packages)
Supported Voltage Range	4.8–5.2V DC (USB) / 44–57V (PoE)
Max. Power Consumption	2.5W
Heat Dissipation	8.5 BTU/hr
Dimensions	107 x 70 x 21 mm (4.2 x 2.8 x 0.8 in)
Weight	150 g (5.3 oz)
Enclosure Material	Polycarbonate
Form Factor	Compact desktop
Operating Temperature	-5 to 45°C (23 to 113°F)
Operating Humidity	10–90% non-condensing
ESD Protection	Air: ±16 kV, Contact: ±12 kV
Certifications	CE, FCC, IC, Anatel
NDAA Compliant	Yes
Software Requirement	UniFi Network (version 5.12.5 and later)
