Ubiquiti UniFi Switch Pro 24 PoE USW-Pro-24-POE – 24-Port Gigabit Layer 3 Managed Switch, 16x PoE+ & 8x PoE++ 802.3bt (400W Budget), 2x 10G SFP+, Near-Silent Cooling, Rackmount

Share to:

Ubiquiti UniFi Switch Pro 24 PoE USW-Pro-24-POE – 24-Port Gigabit Layer 3 Managed Switch, 16x PoE+ & 8x PoE++ 802.3bt (400W Budget), 2x 10G SFP+, Near-Silent Cooling, Rackmount

Ubiquiti USW-Pro-24-PoE is a professional Layer 3 managed PoE switch designed for enterprise, commercial, and high-performance UniFi network deployments. It provides 24 Gigabit Ethernet ports with Power over Ethernet support, allowing businesses to connect and power compatible devices such as UniFi access points, IP phones, security cameras, and other PoE-enabled network equipment through a single network cable. The switch also features high-speed SFP/SFP+ uplink connectivity for flexible network expansion and efficient connection to aggregation or core network infrastructure. Integrated with the UniFi Network platform, the USW-Pro-24-PoE enables centralized configuration, monitoring, VLAN management, traffic control, and network administration through an intuitive interface. Its professional hardware design makes it suitable for offices, schools, hotels, retail environments, surveillance systems, and enterprise networks that require reliable connectivity and centralized management. With a combination of Gigabit switching, PoE capability, high-speed uplinks, Layer 3 functionality, and seamless UniFi ecosystem integration, the Ubiquiti USW-Pro-24-PoE provides a scalable and efficient networking solution for modern business environments.

Model:
USW-Pro-24-POE
Brand:
Ubiquiti
Condition:
Original New
Warranty:
1 year

Availability:

Quantity:



Inquire Add to Basket

Specification	Details
Product Model	USW-Pro-24-POE
Brand	Ubiquiti UniFi
Form Factor	1U Rackmount
Network Ports	24 x 10/100/1000 Mbps RJ45 2 x 1/10G SFP+ Uplink Ports
PoE Ports	16 x PoE+ (802.3at, up to 30W) 8 x PoE++ (802.3bt, up to 60W)
Total PoE Budget	400W
Switching Capacity	88 Gbps
Forwarding Rate	65.472 Mpps
Layer Function	Layer 3 Switching
MAC Address Table	16,000 entries
Max VLAN Quantity	1000
Display	1.3" Touchscreen LCM
Power Supply	Internal 450W AC/DC
AC Input	100–240V AC, 50/60Hz
Redundant Power	USP-RPS DC Input supported
Max Power Consumption	50W (exclude PoE output), 450W (total)
Dimensions	442.4 × 285.4 × 43.7 mm
Weight	4.3kg (without brackets); 4.4kg (with brackets)
Enclosure Material	SGCC Steel
Operating Temperature	-5℃ ~ 40℃ (23℉ ~104℉)
Operating Humidity	10% ~ 90% Non-condensing
ESD Protection	Air: ±16kV, Contact: ±12kV
Cooling	Near-silent built-in fans
Management	UniFi Network Controller (v5.10.5+)
Certifications	CE, FCC, IC
