USW-Pro-Max-48-PoE
Ubiquiti
Original New
1 year
| Availability: | |
|---|---|
| Quantity: | |
Item | Specification |
|---|---|
Product Model | USW‑Pro‑Max‑48‑PoE |
Brand | Ubiquiti UniFi |
Switching Layer | Layer 3UBIQUITI |
RJ45 Ports | 32× GbE RJ45, 16× 1/2.5 GbE RJ45Ubiquiti |
SFP+ Ports | 4× 10G SFP+ Uplink PortsUbiquiti |
PoE Configuration | 32× PoE/PoE+, 16× PoE++(60W)UniFi |
Total PoE Budget | 720WUbiquiti |
Per‑port PoE Max | PoE:15.4W, PoE+:32W, PoE++:64WUniFi |
Switching Capacity | 224 GbpsUbiquiti |
Non‑blocking Throughput | 112 GbpsUbiquiti |
Display | 1.3" Touchscreen LCM DisplayUniFi |
Special Feature | Etherlighting™ Port IndicatorUniFi |
Power Input | 100‑240V AC 50/60Hz, USP RPS DC Backup InputUbiquiti |
Built‑in Power Module | 820W AC/DCUbiquiti |
Max Power Consumption | 100W (excl. PoE), 820W (incl. PoE)UniFi |
Enclosure Material | SGCC SteelUniFi |
Dimensions (W×D×H) | 442.4 × 400 × 44 mm (17.4 × 15.7 × 1.7") |
Weight | 6.2kg (without brackets), 6.3kg (with brackets)UniFi |
Mounting | 19‑inch Rack‑mountable |
Operating Temperature | -5°C ~ 40°C (23°F ~ 104°F)UniFi |
Operating Humidity | 10%‑90% Non‑condensingUniFi |
ESD Protection | Air ±16kV, Contact ±12kVUniFi |
Software Requirement | UniFi Network Controller 8.0.24 or newerUniFi |
Certifications | CE, FCC, IC, Anatel, NDAA CompliantUniFi |
Shenzhen Importgm Technology Co., Ltd.
Shenzhen Importgm Technology Co., Ltd. has been operating in the I T services market since 2010, focusing on the R&D, design and sales of core equipment and general accessories in the field of network communications, we are distributors and resellers of worldwide brands of communication equipment, general accessories and system solutions for global customers.We offer a wide range of products, including networking routers, switches, firewalls, servers, I P phones, video conferencing equipment, wireless A P, P D U and modules. We are located in Shenzhen with convenient transportation access. Over the years we have developed a team of highly skilled staff that delivers quality and effective solutions and services. Based on our rich experience, we can supply products with stable packages, reliable delivery, competitive prices and on-time support. Our products are exported to customers in such regions as the Middle East, Africa, America,Europe and Asia. We also welcome O E M and O D M orders.Whether selecting current products from our inventory or seeking engineering assistance for your project bid, you can consult our business staff at any time. Our service does not end when the invoice is printed but begins as soon as you have received your order. Any customers' business visit and negotiation is warmly welcomed. Let's work together and win-win.





A: The USW-Pro-Max-48-PoE is ideal for enterprise networks, offices, and campuses, providing high-speed connectivity and PoE support for network devices.
A: The USW-Pro-Max-48-PoE can be installed in a standard 19-inch rack. Follow the installation guide for mounting and connection instructions.
A: Regular firmware updates are recommended to maintain optimal performance, improve security, and ensure compatibility with UniFi Network.
A: Alternatives include other Ubiquiti UniFi switches, such as the USW-Pro-48-PoE, which offers different port configurations and features.
A: Check the power supply, Ethernet connections, PoE settings, and port configurations. Ensure the firmware is up to date and review UniFi Network for alerts.
