Ubiquiti UniFi Switch Pro Max 48 USW-Pro-Max-48 – 48-Port Layer 3 Managed Switch with Etherlighting, 32x GbE + 16x 2.5GbE RJ45, 4x 10G SFP+, Fanless Silent Cooling, 1.3" Touchscreen, 1U Rackmount

The Ubiquiti USW-Pro-Max-48 is a high-performance Layer 3 managed Ethernet switch designed for enterprise networks, business offices, campus environments, and professional IT infrastructure. Featuring 48 Ethernet ports, including 32 GbE RJ45 ports and 16 2.5 GbE RJ45 ports, along with 4 10G SFP+ uplink ports, it provides flexible high-speed connectivity for computers, servers, wireless access points, IP phones, and other network devices. With support for VLAN segmentation, advanced traffic management, link aggregation, and Layer 3 switching capabilities, the USW-Pro-Max-48 helps businesses optimize network performance, improve security, and simplify network administration. Its Etherlighting™ technology provides visual port identification for easier installation, monitoring, and troubleshooting, while seamless integration with the UniFi Network application enables centralized configuration, real-time network monitoring, and efficient management of compatible UniFi devices. Designed for scalability, reliability, and high-density network deployments, the Ubiquiti USW-Pro-Max-48 is an excellent choice for organizations seeking a flexible, manageable, and high-capacity switching solution for modern business networks.

  • USW-Pro-Max-48

  • Ubiquiti

  • Original New

  • 1 year

Availability:
Quantity:

Item

Specification

Product Model

USW‑Pro‑Max‑48

Brand

Ubiquiti UniFi

Port Configuration

32×1G RJ45, 16×2.5G RJ45, 4×10G SFP+

Switching Capacity

224 GbpsUniFi

Non‑Blocking Throughput

112 GbpsUniFi

Forwarding Rate

167 MppsUniFi

Switching Layer

Layer 3 SupportedUniFi

MAC Address Table

32000 EntriesUniFi

Max Supported VLANs

1000 VLANsUniFi

Packet Buffer

2 MBUniFi

Management

UniFi Network Controller (v8.0.24+), 1.3" Touch LCM DisplayUniFi

Special Feature

Etherlighting™ Port Indicator, DC Power Backup ReadyUniFi

Form Factor

1U Rack‑Mountable

Enclosure Material

SGCC Steel

Input Voltage

100‑240V AC, 50/60Hz, DC Backup Input Port

Max Power Consumption

100W (No PoE Output)

Dimensions

442 × 325 × 44 mm (17.4 × 12.8 × 1.7")UniFi

Operating Temperature

-5 °C ~ 40 °C (23 °F ~ 104 °F)UniFi

Operating Humidity

10‑90% Non‑condensingUniFi

Certifications

CE, FCC, IC, NDAA CompliantUniFi

Shenzhen Importgm Technology Co., Ltd.

Shenzhen Importgm Technology Co., Ltd. has been operating in the I T services market since 2010, focusing on the R&D, design and sales of core equipment and general accessories in the field of network communications, we are distributors and resellers of worldwide brands of communication equipment, general accessories and system solutions for global customers.We offer a wide range of products, including networking routers, switches, firewalls, servers, I P phones, video conferencing equipment, wireless A P, P D U and modules. We are located in Shenzhen with convenient transportation access. Over the years we have developed a team of highly skilled staff that delivers quality and effective solutions and services. Based on our rich experience, we can supply products with stable packages, reliable delivery, competitive prices and on-time support. Our products are exported to customers in such regions as the Middle East, Africa, America,Europe and Asia. We also welcome O E M and O D M orders.Whether selecting current products from our inventory or seeking engineering assistance for your project bid, you can consult our business staff at any time. Our service does not end when the invoice is printed but begins as soon as you have received your order. Any customers' business visit and negotiation is warmly welcomed. Let's work together and win-win.

gs图片IMG_8380(1)


客户

包装

物流



Q: What are the application scenarios for the USW-Pro-Max-48?

A: The USW-Pro-Max-48 is ideal for enterprise networks, office environments, and campus networks, providing reliable connectivity for multiple wired devices.

Q: How to install the USW-Pro-Max-48 switch?

A: The USW-Pro-Max-48 can be installed in a standard 19-inch rack. Follow the installation guide for mounting and network connection instructions.

Q: Does the USW-Pro-Max-48 need firmware updates?

A: Regular firmware updates are recommended to maintain network security and performance. Updates can be managed through the UniFi Network application.

Q: What are alternative products to the USW-Pro-Max-48?

A: Alternatives include other UniFi switches, such as the USW-Pro-48-PoE, depending on your network requirements and PoE needs.

Q: What are common troubleshooting tips for the USW-Pro-Max-48?

A: Check power connections, inspect Ethernet cables, verify port settings, and ensure the device firmware is up to date.
