Ubiquiti UniFi Switch Pro XG 48 PoE USW-Pro-XG-48-PoE – 48-Port Layer 3 Etherlighting PoE+++ Switch, 32x 10GbE + 16x 2.5GbE RJ45, 4x 25G SFP28, 1080W PoE Budget, 1.3" Touchscreen, 1U Rackmount

Share to:

Ubiquiti UniFi Switch Pro XG 48 PoE USW-Pro-XG-48-PoE – 48-Port Layer 3 Etherlighting PoE+++ Switch, 32x 10GbE + 16x 2.5GbE RJ45, 4x 25G SFP28, 1080W PoE Budget, 1.3" Touchscreen, 1U Rackmount

The Ubiquiti USW-Pro-XG-48-PoE is a high-performance UniFi Pro XG Layer 3 Ethernet switch designed for enterprise networks, data-intensive applications, and high-density PoE deployments. It provides 48 high-speed 10 GbE RJ45 ports with PoE++ support, enabling reliable connectivity and power delivery for compatible Wi-Fi access points, IP cameras, VoIP phones, and other network devices. With high-capacity switching performance, advanced Layer 3 networking features, and seamless integration into the UniFi ecosystem, the USW-Pro-XG-48-PoE helps businesses build scalable, secure, and efficient network infrastructures. It supports centralized management through the UniFi Network application, allowing administrators to configure VLANs, monitor network traffic, manage connected devices, and apply network policies from a unified interface. Designed for demanding business environments, this switch is suitable for enterprise offices, campus networks, conference facilities, surveillance systems, and modern wireless deployments requiring high-speed connectivity and substantial power delivery. By combining multi-gigabit networking, advanced switching capabilities, PoE++ functionality, and centralized network management, the Ubiquiti USW-Pro-XG-48-PoE offers a powerful solution for organizations seeking to upgrade their network infrastructure and support growing bandwidth and connectivity requirements.

Model:
USW-Pro-XG-48-PoE
Brand:
Ubiquiti
Condition:
Original New
Warranty:
1 year

Availability:

Quantity:



Inquire Add to Basket

Item	Specification
Brand	Ubiquiti UniFi
Model	USW‑Pro‑XG‑48‑PoE
Switch Layer	Layer 3UniFi
RJ45 Ports	32×10 GbE PoE+++, 16×2.5 GbE PoE+++ (Total 48 PoE ports)Ubiquiti S...
SFP28 Uplink Ports	4×25G SFP28Ubiquiti S...
Non‑Blocking Throughput	460 GbpsUniFi
Forwarding Rate	684 MppsUniFi
MAC Address Table	128,000 entriesUbiquiti
Supported VLANs	1000Ubiquiti
Packet Buffer	8 MBUbiquiti
Per‑port PoE Output	PoE(15.4W) / PoE+(30W) / PoE++(60W) / PoE+++(90W)UniFi
Total PoE Budget	1080W(200‑240V AC), 972W(100‑120V AC)files.plyt...
Max Power Consumption	200W (without PoE); 1280W(200‑240V), 1172W(100‑120V) with PoEUniFi
Power Supply	Internal 1350W AC/DC, 100‑240V AC 50/60Hz, USP DC backup inputUniFi
Display	1.3" LCM Touch‑screenUniFi
Special Feature	Etherlighting™ Port Indicator, Port Mirroring, Jumbo Frame, LLDP‑MED, ACL, Loop ProtectionUbiquiti N...
ESD Protection	Air ±30kV, Contact ±20kVUniFi
Form Factor	1U 19‑inch Rack‑mountableUbiquiti
Dimensions	442 × 480 × 44 mm (17.4 × 18.9 × 1.7")files.plyt...
Weight	8.8 kg (with mounting brackets)UniFi
Operating Temperature	-5°C ~ 40°C (23°F ~ 104°F)UniFi
Operating Humidity	10%‑90% Non‑condensingUniFi
Enclosure Material	SGCC SteelUniFi
Software Requirement	UniFi Network Controller v9.1.120 or aboveUniFi
Certifications	CE, FCC, IC, NDAA CompliantUniFi
