Ubiquiti UniFi Switch Pro XG 48 USW-Pro-XG-48 – 48-Port Layer 3 Etherlighting Managed Switch, 32x 10GbE + 16x 2.5GbE RJ45, 4x 25G SFP28, 1.3" Touchscreen, 1U Rackmount

Share to:

Ubiquiti UniFi Switch Pro XG 48 USW-Pro-XG-48 – 48-Port Layer 3 Etherlighting Managed Switch, 32x 10GbE + 16x 2.5GbE RJ45, 4x 25G SFP28, 1.3" Touchscreen, 1U Rackmount

The Ubiquiti USW-Pro-XG-48 is a high-performance Layer 3 enterprise switch designed to deliver high-speed, reliable, and scalable network connectivity for modern business environments. Featuring 48 high-speed 10 Gigabit Ethernet ports, it provides substantial bandwidth for demanding applications, including enterprise campus networks, data centers, high-performance workstations, server connectivity, and large-scale business infrastructures. As part of the UniFi switching ecosystem, the USW-Pro-XG-48 supports centralized network management through the UniFi Network application, enabling administrators to configure ports, monitor network performance, manage VLANs, and implement traffic control policies through an intuitive interface. Its advanced switching capabilities help optimize network traffic, improve operational efficiency, and support the integration of servers, storage systems, wireless access points, and other network devices. Designed for professional deployments, this switch offers a scalable foundation for organizations upgrading to multi-gigabit and 10G networking to accommodate growing bandwidth requirements and increasing numbers of connected devices. The Ubiquiti USW-Pro-XG-48 is an excellent choice for enterprises, system integrators, IT infrastructure teams, and network service providers seeking high-density 10GbE connectivity, centralized management, and dependable performance for demanding network environments.

Model:
USW-Pro-XG-48
Brand:
Ubiquiti
Condition:
Original New
Warranty:
1 year

Availability:

Quantity:



Inquire Add to Basket

Item	Specification
Product Model	USW‑Pro‑XG‑48
Brand	Ubiquiti UniFi
Form Factor	1U Rack‑mount
RJ45 Ports	32 × 10 GbE (10G/5G/2.5G/1G/100M/10M), 16 × 2.5 GbE (2.5G/1G/100M/10M)
SFP28 Uplink Ports	4 × 25G SFP28 (25G/10G/1G)
Switching Layer	Layer 3
Switching Capacity	920 Gbps
Non‑Blocking Throughput	460 Gbps
Forwarding Rate	684 Mpps
MAC Address Table	32,000 entries
Supported VLANs	1000
Packet Buffer	8 MB
Display	1.3‑inch LCM Touchscreen
Special Feature	Etherlighting™ Port Indicator
Power Input	100‑240V AC 50/60Hz, Internal Power Supply, DC Backup Support
Max Power Consumption	250W
ESD Protection	Air: ±30kV, Contact: ±14kV
Operating Temperature	-5 °C ~ 40 °C (23 °F ~ 104 °F)
Operating Humidity	10%‑90% Non‑condensing
Enclosure Material	SGCC Steel
Dimensions (W×D×H)	442 × 480 × 44 mm
Weight	7.5kg (without brackets), 7.6kg (with brackets)
Certifications	CE, FCC, IC
Management	UniFi Network Controller, Ethernet AR Management
