Ubiquiti UniFi Switch Ultra 60W USW-Ultra-60W – Compact 8-Port Layer 2 GbE PoE Switch, 7x PoE+ Output Ports, 1x PoE++ Input, 52W PoE Budget with 60W AC Adapter, Wall/Desktop/Magnetic Mount

Share to:

Ubiquiti UniFi Switch Ultra 60W USW-Ultra-60W – Compact 8-Port Layer 2 GbE PoE Switch, 7x PoE+ Output Ports, 1x PoE++ Input, 52W PoE Budget with 60W AC Adapter, Wall/Desktop/Magnetic Mount

The Ubiquiti USW-Ultra-60W is a compact, high-performance UniFi Layer 2 Gigabit Ethernet switch designed for small and medium-sized businesses, offices, retail stores, and enterprise network deployments. Featuring 8 Gigabit Ethernet ports, including 7 PoE+ output ports and 1 PoE++ input port, it provides flexible connectivity and convenient Power over Ethernet support for compatible UniFi access points, IP cameras, VoIP phones, and other network devices. With a total PoE power budget of up to 52W when powered by the included 60W adapter, the USW-Ultra-60W simplifies network installation by delivering data and power over a single Ethernet cable, helping reduce cabling requirements and deployment costs. Its compact, space-saving design makes it suitable for desktop installation and locations where rack space is limited, while seamless integration with the UniFi Network application enables centralized configuration, real-time monitoring, and efficient network management. The switch supports VLAN segmentation, traffic monitoring, and other essential network management features to help businesses maintain an organized and reliable network infrastructure. Combining Gigabit connectivity, PoE flexibility, compact dimensions, and centralized UniFi management, the Ubiquiti USW-Ultra-60W is an ideal solution for expanding business networks and powering compatible devices in modern office and commercial environments.

Model:
USW-Ultra-60W
Brand:
Ubiquiti
Condition:
Original New
Warranty:
1 year

Availability:

Quantity:



Inquire Add to Basket

Item	Specification
Brand	Ubiquiti UniFi
Model	USW‑Ultra‑60W
Switch Layer	Layer 2
Network Ports	8 x GbE RJ45 Ports
PoE Output Ports	7 x PoE/PoE+ (802.3af/at)
PoE Input Port	1 x PoE++ (802.3bt) uplink port
Switching Capacity	16 Gbps
Non‑Blocking Throughput	8 Gbps
Forwarding Rate	11.904 Mpps
Total Available PoE Budget	52W (with included 60W AC adapter); 42W (PoE++ input)
Per‑port PoE Max.	30W (PoE+)
Power Supply	54V DC, 1.1A, 60W External AC‑DC Adapter (Included)
Power Input Options	DC adapter, PoE++
Supported Input Voltage	44‑57V DC
Max Power Consumption (Unit only, exclude PoE output)	8W (AC adapter input); 9W (PoE++ input)
Management	UniFi Network Controller, Ethernet In‑Band Management
Indicators	System Status, Link/Activity, PoE Status LED
Reset Button	Factory Reset
Enclosure Material	Polycarbonate
Dimensions	203 × 76 × 33 mm (8 × 3 × 1.3")
Weight	Unit: 320 g; Wall‑mount bracket: 45 g; Adapter: 330 g
Operating Temperature	-20°C ~ +45°C (AC adapter power); -30°C ~ +60°C (PoE++ power input)
Operating Humidity	10‑90% Non‑condensing
Mounting	Wall‑mount, Desktop placement
