Product Descriptio
Ultra HD 4K Camera | • Ultra HD 4K camera • 1920 x 1080 video resolution • 30 frame rate • 4x e-PTZ camera • Horizontal field of view: 103° |
Microphone | • Built-in six beamforming microphone arrays • 16ft / 5 meters voice pickup distance • Wireless microphone (optional) • Conference phone CP960 (optional) |
Video Standard and Network Suitability | • Video codecs: H.265/HEVC, H.264 High Profile, H.264, H.263, H.263+ • Forward Error Correction (FEC) • Anti 30% video packet loss • Bandwidth dynamic adaptive adjustment • Shared content and audio preference strategy • Bandwidth/protocol/audio&video call auto adaptive |
Audio Features | • Audio codecs: - Opus, 8~48kHz sampling rate - 14kHz bandwidth with G.722.1C - 7kHz bandwidth with G.722.1 - 3.4kHz bandwidth with G.711 (PCMA/PCMU) - G.729 - ARES • Audio technology: - Acoustic echo cancellation - Automatic gain control - Yealink Noise Proof Technology - CNG, PLC, AJB, De-Rerb |
Operating System | • Based on Android 7.1 |
Call Features | • 1080P30 people + 1080P30 content sharing video quality • Video Layout: Picture-in-picture (PIP) • Video/audio recording and playback • Screenshots in USB flash drive, local storage or YMS • Group dial • YMS meeting control: - invite/remove - mute/unmute participates - lock • DND (do not disturb), call statistics • Auto answer, mute, call waiting • Virtual keyboard • Local directory: 500 entries • Call history: all/missed/received/dialed • LDAP phonebook • Multi-language support • Additional five-way audio call |
Standard Communication Protocol | • H.323/SIP • Dual stream protocol: H.239 (H.323)/BFCP (SIP) • FECC: H.224/H.281, Sony VISCA and PELCO D/P • H.323 protocol suite: H.245, H.225, H.235, H.241 • Gatekeeper account and SIP account |
Network and Security Features | • Built-in dual-band Wi-Fi (2.4GHz/5GHz): - connect to a Wi-Fi network - serve as a Wi-Fi hotspot • Built-in Bluetooth • IPv4 and IPv6, DHCP/static IP • HTTP/HTTPS web server • RS232/HTTP API for control system integration • SRTP/TLS, AES 256-bit encryption • QoS: 802.1p/q, Diff-serv • VLAN, IEEE802.1X, LLDP-MED • Anti-attack • Network diagnosis: Ping, trace route • Time and date synchronization using SNTP • Built-in certificate |
NAT and Firewall Traversal | • ICE/TURN/STUN • H.460 • NAT (manual/auto mode) • Yealink intelligent firewall traversal • Open VPN |
VC200 Codec Connections | • 1 x HDMI output (CEC supported) • 1 x Yealink extension port (RJ-45) connect to VCH50/VCH51/CP960 Phone • 1 x 10/100M Ethernet port: • Power over Ethernet (IEEE 802.3af) • 2 x USB 2.0 • 1 x Line-out (3.5mm) • 1 x security lock slot • 1 x reset slot |
Confifiguration Management | • Configuration via browser/display/CTP20/auto-provisioning • Virtual remote control • Firmware upgrading, factory resetting • Export or import configuration • System log exporting |
Physical Features | • Color: Space Silver • Capacity: 16GB (Available: 8GB) • Yealink PoE Adapter: AC 100~240V input • Power consumption (PSU): Idle < 6.5W; Normal: 7W; MAX: 8W • USB Output: 5V 500mA • Dimension (W.D.H): - VC200 codec: 300 mm x 70 mm x 86.6 mm - VCR11: 190mm x 55mm x 24mm • Operating humidity: 10~95% • Operating temperature: 0~40°C • Storage temperature: -30~70°C |
Package features | • Qty/CTN: 4 PCS • Giftbox size: 355mm*135mm*140mm • Carton Meas: 375mm*335mm*355mm |
Package includes | • VC200 Codec (integrate codec/camera/microphone/bracket ) • VCR11 Remote Control • PoE Adapter • WPP20 Wireless Presentation Pod (optional) • VCH50/VCH51 Video Conferencing Hub (optional) |
Product Descriptio
Ultra HD 4K Camera | • Ultra HD 4K camera • 1920 x 1080 video resolution • 30 frame rate • 4x e-PTZ camera • Horizontal field of view: 103° |
Microphone | • Built-in six beamforming microphone arrays • 16ft / 5 meters voice pickup distance • Wireless microphone (optional) • Conference phone CP960 (optional) |
Video Standard and Network Suitability | • Video codecs: H.265/HEVC, H.264 High Profile, H.264, H.263, H.263+ • Forward Error Correction (FEC) • Anti 30% video packet loss • Bandwidth dynamic adaptive adjustment • Shared content and audio preference strategy • Bandwidth/protocol/audio&video call auto adaptive |
Audio Features | • Audio codecs: - Opus, 8~48kHz sampling rate - 14kHz bandwidth with G.722.1C - 7kHz bandwidth with G.722.1 - 3.4kHz bandwidth with G.711 (PCMA/PCMU) - G.729 - ARES • Audio technology: - Acoustic echo cancellation - Automatic gain control - Yealink Noise Proof Technology - CNG, PLC, AJB, De-Rerb |
Operating System | • Based on Android 7.1 |
Call Features | • 1080P30 people + 1080P30 content sharing video quality • Video Layout: Picture-in-picture (PIP) • Video/audio recording and playback • Screenshots in USB flash drive, local storage or YMS • Group dial • YMS meeting control: - invite/remove - mute/unmute participates - lock • DND (do not disturb), call statistics • Auto answer, mute, call waiting • Virtual keyboard • Local directory: 500 entries • Call history: all/missed/received/dialed • LDAP phonebook • Multi-language support • Additional five-way audio call |
Standard Communication Protocol | • H.323/SIP • Dual stream protocol: H.239 (H.323)/BFCP (SIP) • FECC: H.224/H.281, Sony VISCA and PELCO D/P • H.323 protocol suite: H.245, H.225, H.235, H.241 • Gatekeeper account and SIP account |
Network and Security Features | • Built-in dual-band Wi-Fi (2.4GHz/5GHz): - connect to a Wi-Fi network - serve as a Wi-Fi hotspot • Built-in Bluetooth • IPv4 and IPv6, DHCP/static IP • HTTP/HTTPS web server • RS232/HTTP API for control system integration • SRTP/TLS, AES 256-bit encryption • QoS: 802.1p/q, Diff-serv • VLAN, IEEE802.1X, LLDP-MED • Anti-attack • Network diagnosis: Ping, trace route • Time and date synchronization using SNTP • Built-in certificate |
NAT and Firewall Traversal | • ICE/TURN/STUN • H.460 • NAT (manual/auto mode) • Yealink intelligent firewall traversal • Open VPN |
VC200 Codec Connections | • 1 x HDMI output (CEC supported) • 1 x Yealink extension port (RJ-45) connect to VCH50/VCH51/CP960 Phone • 1 x 10/100M Ethernet port: • Power over Ethernet (IEEE 802.3af) • 2 x USB 2.0 • 1 x Line-out (3.5mm) • 1 x security lock slot • 1 x reset slot |
Confifiguration Management | • Configuration via browser/display/CTP20/auto-provisioning • Virtual remote control • Firmware upgrading, factory resetting • Export or import configuration • System log exporting |
Physical Features | • Color: Space Silver • Capacity: 16GB (Available: 8GB) • Yealink PoE Adapter: AC 100~240V input • Power consumption (PSU): Idle < 6.5W; Normal: 7W; MAX: 8W • USB Output: 5V 500mA • Dimension (W.D.H): - VC200 codec: 300 mm x 70 mm x 86.6 mm - VCR11: 190mm x 55mm x 24mm • Operating humidity: 10~95% • Operating temperature: 0~40°C • Storage temperature: -30~70°C |
Package features | • Qty/CTN: 4 PCS • Giftbox size: 355mm*135mm*140mm • Carton Meas: 375mm*335mm*355mm |
Package includes | • VC200 Codec (integrate codec/camera/microphone/bracket ) • VCR11 Remote Control • PoE Adapter • WPP20 Wireless Presentation Pod (optional) • VCH50/VCH51 Video Conferencing Hub (optional) |
