Yealink T57W Prime Business Phone Optional(T57W+EXP50) VoIP phone SIP-T57W

  • SIP-T57W
  • Yealink
  • original new
  • 1 year
Quantity:

Product Description

Yealink T57W Prime Business Phone Optional(T57W+EXP50) Voip phone SIP-T57W
Prime Business Phone to Deliver Optimum Desktop Productivity
SIP-T57W
• 7" 800 x 480 capacitive adjustable touch screen
• Adjustable LCD screen
• Dual firmware images
• T53/T53W/T54W/T57W firmware unified
• Built-in Bluetooth 4.2
• Built-in dual band 2.4G/5G Wi-Fi (802.11a/b/g/n/ac)
• USB 2.0 port for USB recording, wired/wireless USB headsets and EXP50
• Up to 16 VoIP accounts
• Dual-port Gigabit Ethernet
• PoE support
• HAC Handset
• Paperless label design
• Wall mountable
downLoadImg(7) Key Features
1.Outstanding User Experience
Yealink SIP-T57W IP Phone features an adjustable 7-inch capacitive touch screen that you can readily adjust it to the comfortable viewing angle according to yourself. In addition, clearly defined set of menus is easy to navigate through when all you have to do is touching the desired option, that ensuring you an optimized interface for a smartphone-like user experience.
2.HD Audio
The SIP-T57W is coupled with the latest version of Yealink Optimal HD Voice technologies, including Yealink Acoustic Shield technology, that effectively eliminate background distractions and noises, deliver crystal clear voice even in a noisy environment. Meanwhile, complying with the latest Hearing Aid Compatibility (HAC) Regulations, its HAC handset helps the person who is with hearing loss to hear the voice more clearly.
3.High Expandability
A built-in USB 2.0 port allows you to enjoy USB call recording via USB flash drive. Via this USB port, you also can connect wired/wireless USB headset without connecting Yealink EHS36 anymore, and connect up to 3 Yealink expansion modules EXP50 which can be programmed with up to 180 paperless DSS keys
4.Efficient Installation and Provisioning
The Yealink SIP-T57W supports efficient provisioning and effortless mass deployment with Yealink's Redirection and Provisioning Service (RPS) and Boot mechanism to help you realize the Zero Touch Provisioning without any complex manual settings. Furthermore, a unified firmware and auto-p template that applies to T53/T53W/T54W/T57W phone models, saves even more time and costs for businesses, as well as simplifies the management and maintenance.
5.Wireless Transmission
Yealink SIP-T57W IP Phone not only furnish you with the built-in Bluetooth 4.2 for Bluetooth headsets and mobile contacts synchronization, but also the built-in dual band Wi-Fi for Wi-Fi connectivity, allowing you to access the 5G Wi-Fi connectivity handily. Also if you want to expand your horizons for busy environments, or, share one phone system with your small team by adding multiple handsets, just simply turn your IP phone to the corded-cordless phone via DECT technology. Moreover, the IP phone can function with Yealink VC Desktop together to share content from your laptop, making collaboration much easier than before.
Specification
Audio features
• HD voice: HD handset, HD speaker
Hearing aid compatible (HAC) handset
Acoustic Shield
Smart Noise Filtering
• Audio codec: Opus, G.722, PCMA, PCMU, G.729A/B, G.726, G.723.1, iLBC
• DTMF: In-band, Out-of-band (RFC 2833) and SIP INFO
Full-duplex hands-free speakerphone with AEC
• VAD, CNG, AEC, PLC, AJB, AGC
Display and Indicator
7" 800 x 480 capacitive adjustable touch screen
• LED for call and message waiting indication
• Dual-color (red or green) illuminated LEDs for line status information
Wallpaper
Intuitive user interface with icons and soft keys
Multilingual user interface
Caller ID with name, number and photo
Screensaver
Power saving
Phone Features
16 VoIP accounts
One-touch speed dial, hotline
Call forward, call waiting, call transfer
Mute, DND, call hold, redial, call return, auto answer
Group listening, SMS, emergency call
10-way conferencing
Direct IP call without SIP proxy
Ring tone selection/import/delete
Set date time manually or automatically
• Dial plan, XML Browser, Action URL/URI
RTCP-XR (RFC3611), VQ-RTCPXR (RFC6035)
• Built-in dual band Wi-Fi:
- Network standard: IEEE802.11a/b/g/n/ac
- Transmission rate: Up to 433Mbps (dynamic)
- Frequency range: 2.4GHz/5.0GHz
• Built-in Bluetooth for:
- Bluetooth headset,
- Mobile contacts synchronization
- Bluetooth call
- Simultaneous connection of one headset and one mobile phone
• USB port (2.0 compliant) for:
- Wired/wireless USB headset
- USB call recording through USB flash drive
- Color-screen expansion modules EXP50 (up to 3)
- Wireless Headset Adapter EHS40
USB/Bluetooth connectivity to Yealink CP900/CP700  speakerphone, USB connectivity to Yealink UH36 headset:
- Basic functions: Answer / end, call mute
- Enhanced function: audio optimization, redial, call hold, volume synchronization, multiple calls control
• Content Sharing (via Yealink VCD)
Enhanced DSS key
Corded-Cordless Phone (via DECT Dongle DD10K)
Up to 4 DECT cordless handsets
Up to 4 concurrent calls
• Support Yealink W52H/W53H/W56H/DD Phone/CP930W
Slave Handset for Master Deskset
IP-PBX Features
• Busy Lamp Field (BLF), Bridged Line Apperance (BLA)
Anonymous call, anonymous call rejection
Hot-desking, voice mail
Flexible seating, Executive and Assistant
Call park, call pickup
Centralized call recording, call recording
Directory
• Local phonebook up to 1000 entries
Black list
• XML/LDAP remote phonebook
Google contacts
Smart dialing
Phonebook search/import/export
• Call history: dialed/received/missed/forwarded
Feature keys
29 one-touch DSS keys
• 7 feature keys: hold, transfer, message, headset, mute, redial, speakerphone
Volume control keys
Illuminated mute/headset/hands-free speakerphone key
Interface
Dual-port Gigabit Ethernet
Power over Ethernet (IEEE 802.3af)
1 x USB port (2.0 compliant)
• 1 x RJ9 (4P4C) handset port
• 1 x RJ9 (4P4C) headset port
Management
• Configuration: browser/phone/auto-provision
Auto provision via FTP/TFTP/HTTP/HTTPS for mass deploy
Auto-provision with PnP
Broadsoft device management
Zero-sp-touch, TR-069
Phone lock for personal privacy protection
Reset to factory, reboot
Package tracing export, system log
Network and Security
SIP v1 (RFC2543), v2 (RFC3261)
Call server redundancy supported
• NAT traversal: STUN mode
Proxy mode and peer-to-peer SIP link mode
• IP assignment: static/DHCP/PPPoE
HTTP/HTTPS web server
Time and date synchronization using SNTP
UDP/TCP/DNS-SRV(RFC 3263)
• QoS: 802.1p/Q tagging (VLAN), Layer 3 ToS DSCP
SRTP for voice
• Transport Layer Security (TLS1.2)
HTTPS certificate manager
AES encryption for configuration file
Digest authentication using MD5/MD5-sess
OpenVPN, IEEE802.1X
• IPv6, LLDP/CDP/DHCP VLAN, ICE
Other Physical Features
• Color: Classic Grey
Wall mountable (optional)
• External Yealink AC adapter (optional): AC 100~240V input and DC 5V/2A output
• USB output currency: 5V 500mA
• Power consumption (PSU): 3.2W-6.3W
• Power consumption (PoE): 4.0W-7.8W
• Dimension (W*D*H*T): 259.4mm*220mm*211mm*44.5mm
• Operating humidity: 10~95%
• Operating temperature: -10~50°C (+14~122°F)
Package features
• Package content:
- Yealink SIP-T57W IP phone
- Handset with handset cord
- Ethernet Cable
- Stand
- Quick Start Guide
- Power Adapter (Optional)
• Qty/CTN: 5 PCS
• N.W/CTN: 8.86 kg
• G.W/CTN: 9.79 kg
• Giftbox size: 324 mm*293 mm*128 mm
• Carton Meas: 680 mm* 303 mm*342 mm

Yealink-T57W-Datasheet.pdf
